| Specifications | ASTM A240, A928 / ASME SA240, SA928 |
| Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381) EN 10151 EN 10088 |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
If you are looking for best prices for Super Duplex Strip, Foil, Sheet email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Super Duplex Steel Sheet Price | US $1300-1900 / Ton |
| Super Duplex Stainless Steel Sheet Price | US $1000-3000 / Ton |
| SDSS Plate Price Per KG | US $1000-2500 / Ton |
| 6mm Super Duplex Steel Sheet Price | S $1000.0-1000.0 / Ton |
| Super Duplex Stainless Steel Sheet Price Per KG | US $2000-2500 / Ton |
| Super Duplex Stainless Steel Sheet Price Per KG | US $1300-3700 / Ton |
| SDSS Chequered Plate Price | US $1500-2500 / Ton |
| Polished Super Duplex Steel Plate Price List | US $1200-5000 / Ton |
| Super Duplex Steel Shim Sheet Price List | US $1.3-2.7 / Kilogram |
| 10mm Thick Super Duplex Steel Plate Price | US $2,600.00/ Ton |
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
|---|---|---|---|---|---|---|
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
| Weight per | Size | Size | Weight per | ||||
| Sheets (Kg) | (mm) | (mm) | Sheets (Kg) | ||||
| 12.8 | 2500 x | 1250 x | 0.5 | 2000 x | 1000 x | 1.5 | 24.6 |
| 8.2 | 2000 x | 1000 x | 0.5 | 3000 x | 1500 x | 1.2 | 44.2 |
| 17.9 | 2500 x | 1250 x | 0.7 | 3000 x | 1500 x | 1.5 | 55.3 |
| 13.1 | 2000 x | 1000 x | 0.8 | 2000 x | 1000 x | 2.0 | 32.7 |
| 11.5 | 2000 x | 1000 x | 0.7 | 2500 x | 1250 x | 1.5 | 38.4 |
| 14.7 | 2000 x | 1000 x | 0.9 | 3000 x | 1500 x | 2.0 | 73.7 |
| 20.5 | 2500 x | 1250 x | 0.8 | 2500 x | 1250 x | 2.0 | 51.2 |
| 33.2 | 3000 x | 1500 x | 0.9 | 2500 x | 1250 x | 2.5 | 63.9 |
| 36.8 | 3000 x | 1500 x | 1.0 | 2500 x | 1250 x | 3.0 | 77.5 |
| 23.0 | 2500 x | 1250 x | 0.9 | 2000 x | 1000 x | 2.5 | 40.9 |
| 25.6 | 2500 x | 1250 x | 1.0 | 2000 x | 1000 x | 3.0 | 49.6 |
| 16.4 | 2000 x | 1000 x | 1.0 | 3000 x | 1500 x | 2.5 | 92.1 |
| 19.6 | 2000 x | 1000 x | 1.2 | 3000 x | 1500 x | 3.0 | 112.0 |
| 30.7 | 2500 x | 1250 x | 1.2 | - | - | - | - |
Ask Free Sample of Super Duplex Stainless Steel Sheet, Plate, Coil, Strip, Flat Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A240 Super Duplex Steel Plates Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
PMI Testing
Hydrostatic Test
Radiography Test
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed Sheet | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled Sheet | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| Products We Supplied | Description | Country |
| 3mm Super Duplex Steel Sheet | Super Duplex Hot Rolled Sheets Supply | Serbia, Venezuela, Germany, Malaysia |
| ASTM A240 Super Duplex Sheets | 6mm Thick Super Duplex Steel 1.4410 Sheet | South Africa, Azerbaijan, Gambia, Belarus, Oman |
| Super Duplex Steel Perforated Sheets | 0.35mm Cold Rolled Super Duplex Sheets | Slovakia, Yemen, Mongolia, Puerto Rico, Romania |
| Mirror Finish Super Duplex Steel Sheet | 0.8mm Double Color Mirror Finish | Singapore, Hong Kong, Australia, Switzerland |
| ASME SA240 Super Duplex Steel Coils | 1.4410 Cold Rolled Slitting Coils | Taiwan, New Zealand, Belgium, Portugal |
| Super Duplex Stainless Steel HR Plate | 10mm Thick Super Duplex Steel Plate | Ecuador, Chile, Jordan, Czech Republic, Nigeria |
| Super Duplex Steel Polished Plates | 16 Gauge Plates | Bulgaria, Kuwait, Nepal, Bhutan |
| Super Duplex Steel 3/16" Plate | 8k Mirror Finish Super Duplex Steel Plate | Denmark, Hungary, Estonia, Vietnam |
Oil & Gas
Chemical
Power Generation
Aerospace
Heavy Equipment
Automotive
Shipbuilding
Construction
