Super Duplex Steel S32760 Flange

Duplex Steel & Alloys is a supplier of Super Duplex Steel S32760 Flange in a range of thicknesses, lengths, and grades.
Point to note about Super Duplex Flanges:
Super Duplex UNS S32760 is a popular super duplex grade on the market. Super Duplex Steel is duplex stainless steel with W and Cu additions to UNS S32760 that is specifically suited for use in harsh chloride-containing environments. It possesses excellent resistance to localized corrosion and stress corrosion cracking, as well as strong mechanical strength.

The major uses are for details with high resistance to corrosion standards.
• High resistance to stress corrosion cracking in halide-containing conditions characterizes UNS S32760.
• Pitting and Crevice Corrosion Resistance is excellent.
• High General Protection against Corrosion.
• Mechanical Strength is Quite High.
• Highly Resistant to Erosion, Oxidation, and Fatigue.
• Tensile and yield strength have been increased.
• Excellent Flexibility And Tenacity
• Resistance to SSC
• Reasonably priced

Super Duplex Stainless Steel S32760 Flange, Super Duplex Steel S32760 Flange, Duplex S32760 Flange Price List, UNS S32760 Flange, Super Duplex Steel S32760 Flange Suppliers in Mumbai, India.

Table of Content

ASTM A182 F55 Flange, Super Duplex Steel S32760 Flanges Suppliers, ASTM A182 S32760 Super Duplex Steel Flanges, SSDSS S32760 Blind Flange, S32760 Spectacle Blind Flange, Super Duplex Steel S32760 Slip On Flange, Super Duplex Steel S32760 Flange Manufacturers in India.

Stainless Steel 304 Flanges

Our UNS S32760 Super Duplex Steel Flanges feature high strength, exceptional resistance to chloride-induced stress cracking, and outstanding resistance to sulphide-stress corrosion cracking in sour-gas conditions. Super Duplex Steel S32760 Flanges have excellent resistance to weathering stress.
These Flanges are used in several applications including:
• Oil and Gas Applications
• Hydropower
• Pressure Vessels
• Structural Components
• Chemical Tankers
• Seawater Applications
• Marine Applications
• Flue Gas Scrubbing Equipment
• Pulp & Paper Industry
• Offshore Oil Refining
• Subsea Pipework Systems
• Heat Exchangers

Super Duplex Steel S32760 Flanges have high weldability. The welding processes are the same as for typical duplex grades. Because of its optimum incorporation feature, Super Duplex Steel S32760 Flanges have greater machinability versus equivalent super duplex grades. We provide high-quality Duplex Steel Flanges in a variety of sizes and forms that are intended to meet National & International raw materials quality standards. Our Super Duplex Steel Flanges are also available in custom lengths and forms.


Super Duplex Steel S32760 Flanges Specification

Standard ASTM A182 / ASME SA182
Dimensions ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flange, ASME/ANSI B16.5/16.36/16.47A/16.47B, MSS S44, ISO70051, JISB2220, BS1560-3.1, API7S-15, API7S-43, API605, EN1092
Flange Size Chart 1/2" (15 NB) to 48" (1200NB), DN10~DN5000
Pressure Rating Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS
Pressure Calculation in DIN 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64
JIS 16 K, 5K, 10 K, 20 K, 30 K, 40 K, 63 K
Flange Connection / Flange Face Type Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove, Groove, Flange Pipe.
Origin West Europe / Japan / Indian / USA / Korean
Types of Flanges Threaded / Screwed / Forged / Plate
Coating Yellow Transparent, Zinc Plated, Anti-rust Paint, Oil Black Paint, Cold and Hot Dip Galvanized
Test Of Flange Direct-reading Spectrograph, Ultrasonic flaw detector, Magnetic particle detector, X-ray detector, Hydrostatic testing machine.
Production technique Used Heat treated, Forged and Machined
Equipment Press machine, Bending machine, Pushing Machine, Sand-blasting machine, electric bevelling machine etc.
Test Certificates EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report, etc

Types of Super Duplex Steel S32760 Flanges

SORF Flange

S32760 Super Duplex Stainless Steel Slip On Flange

Plate Flanges

Super Duplex Stainless Steel S32760 Plate Flanges

Weld Neck Flange

UNS S32760 Welding Neck Flange

Blind Flange

Duplex S32760 Blind Flange

Spectacle Blind Flange

S32760 Spectacle Blind Flange

Socket Weld Flange

Super Duplex Steel S32760 Socket Weld Flange

Threaded Flange

ASTM A182 UNS S32760 Threaded Flange

Lap Joint Flange

S32760 Super Duplex Stainless Steel Lap Joint Flange

Ring Type Joint Flange

Super Duplex Stainless Steel S32760 RTJ Flange

Long Weld Neck Flange

UNS S32760 Long Weld Neck Flange

Tongue and Groove Flange

SDSS S32760 Tongue and Groove Flange

Orifice Flange

S32760 Super Duplex Steel Orifice Flange

UNS S32760 Flange Equivalent

STANDARD WERKSTOFF NR. UNS
Super Duplex Steel 1.4410 S32760

UNS S32760 Flange Chemical Composition

Grade C Mn Si P S Cr Mo Ni N Fe
S32760 0.05 max 1.00 max 1.00 max 0.030 max 0.010 max 24.00 – 26.00 3.00 – 4.00 6.00 – 8.00 0.20 – 0.30 57.61 min

Duplex S32760 Flange Mechanical Properties

Grades Density (g/cm 3) Density (lb/in 3) Melting Point (°C) Melting Point (°F)
S32760 7.8 0.281 1350 2460

ASME B16.5 Super Duplex Steel S32760 Flanges, S32760 Super Duplex Steel SORF Flange, S32760 Super Duplex Stainless Steel Pipe Flange, Duplex S32760 Flange Supplier, UNS S32760 Flanges Suppliers in Mumbai.

If you are looking for best prices for Super Duplex Steel S32760 Flanges, UNS S32760 Flange, S32760 Pipe Flange email us on info@duplexsteelalloys.com or call us on +91 9664408767

Looking to Buy Super Duplex Steel S32760 Flange ?

UNS S32760 Flange Price List S32760 Duplex Flange Price List India UNS S32760 Flange Weight Calculator

S32760 Super Duplex Stainless Steel Flange Price List

Product Price
S32760 Super Duplex Stainless Steel Flange Price List US $8.72-21.57 / Piece
S32760 Super Duplex Steel Slip on Flange Price US $13.58-30.23 / Piece
Super Duplex Steel S32760 Weld Neck Flange Price List US $8.72-13.58 / Piece
S32760 Super Duplex Steel Square Flange Price List S $13.56-28.23 / Piece
S32760 Super Duplex Steel Orifice Flange Price US $6.82-21.57 / Piece
SDSS S32760 2 Inch Pipe Flange Price US $15.58-28.45 / Piece
Super Duplex Stainless Steel S32760 Lapped Flange Price US $15.86-31.33 / Piece
UNS S32760 Threaded Flange Prices US $5.52-19.47 / Piece
S32760 Super Duplex Steel Blind Flange Price US $1.2-2.9 / Kilogram
Super Duplex Steel S32760 Spectacle Blind Flange Price US $2,100.00-3,500.00 / Ton

S32760 Super Duplex Steel Flanges Pressure and Temperature Ratings

Temperature °F Class 150 Class 600 Class 1500 Class 400 Class 900 Class 300 Class 2500
-20 to 100 275 1440 3600 960 2160 720 6000
300 205 1080 2700 720 1620 540 4500
200 230 1200 3000 800 1800 600 5000
400 190 995 2485 660 1490 495 4140
600 140 875 2185 580 1310 435 3640
650 125 860 2150 575 1290 430 3580
500 170 930 2330 620 1395 465 3880
700 110 850 2125 565 1275 425 3540
750 95 830 2075 555 1245 415 3460
850 65 790 1980 530 1190 395 3300
800 80 805 2015 540 1210 405 3360
900 50 780 1945 520 1165 390 3240
950 35 765 1910 510 1145 380 3180
1000 20 640 1605 430 965 320 2675
1100 20 515 1285 345 770 255 2145
1150 20 400 995 265 595 200 1655
1050 20 615 1545 410 925 310 2570
1200 20 310 770 205 465 155 1285
1250 20 225 565 150 340 115 945
1300 20 170 430 115 255 85 715
1400 20 95 240 65 145 50 400
1350 20 125 310 80 185 60 515
1450 15 70 170 45 105 35 285
1500 10 55 135 35 80 25 230

S32760 Super Duplex Stainless Steel Flange Weight Chart

NPS (Nominal Pipe Size) Loose (Lap Joint) NPT (Threaded) SORF (Slip On) BLRF (Blind) SWRF (Socket Weld) WRNR (Weld Neck)
½ 1 1 1 2 2 2
1 2 2 2 2 2 3
1¼ 3 3 3 3 3 3
¾ 2 2 2 2 2 2
1½ 3 3 3 4 3 4
2½ 8 8 8 7 8 10
2 5 5 5 5 5 6
3 9 9 9 9 9 11.5
4 13 13 13 17 13 16.5
3½ 11 12 11 13 11 12
5 15 15 15 20 15 21
8 30 30 30 47 30 42
6 19 19 19 27 19 26
10 43 43 43 70 43 54
24 275 220 220 430 220 268
14 105 90 90 140 90 114
12 64 64 64 123 64 88
16 140 98 106 180 98 140
20 195 165 165 285 165 197
18 160 130 130 220 130 165
22 245 185 185 355 185 225

Super Duplex Steel S32760 Flange Dimensions

Normal Pipe Size (NPS) Of Flanges (I.D.) Inside Diameter Thickness Of Raised Face (RF)
(T)		 Outside Daimeter (O.D.) Raised Face
(R)		 RF
(Raised Face)		 Holes Of Bolts
(B)		 H T1 Thickness Of Flat Face (FF)
(T2)		 BC (Circle Of Bolt) Bolts Holes
Numbers
1/2 0.88 0.88 3.75 1.38 .063 0.62 1.50 0.50 0.82 2.62 4
1 1.36 1.06 4.88 2.00 .063 0.75 2.12 0.63 1.00 3.50 4
3/4 1.09 1.00 4.62 1.69 .063 0.75 1.88 .056 0.94 3.25 4
1-1/4 1.70 1.06 5.25 2.50 .063 0.75 2.50 0.69 1.00 3.88 4
2 2.44 1.31 6.50 3.62 .063 0.75 3.31 0.82 1.25 5.00 8
1-1/2 1.95 1.19 6.12 2.88 .063 0.88 2.75 0.75 1.13 4.50 4
2-1/2 2.94 1.50 7.50 4.12 .063 0.88 3.94 0.94 1.44 5.88 8
3 3.57 1.69 8.25 5.00 .063 0.88 4.62 1.06 1.63 6.62 8
3-1/2 4.07 1.75 9.00 5.50 .063 0.88 5.25 1.13 1.69 7.25 8
4 4.57 1.88 10.00 6.19 .063 0.88 5.75 1.19 1.82 7.88 8
5 5.66 2.00 11.00 7.31 .063 0.88 7.00 1.32 1.94 9.25 8
18 18.18 3.50 28.00 21.00 .063 1.38 21.00 2.32 3.44 24.75 24
6 6.72 2.06 12.50 8.50 .063 0.88 8.12 1.38 2.00 10.62 12
8 8.72 2.44 15.00 10.62 .063 1.00 10.25 1.56 2.38 13.00 12
10 10.88 2.62 17.50 12.75 .063 1.12 12.62 1.82 2.56 15.25 16
12 12.88 2.88 20.50 15.00 .063 1.25 14.75 1.94 2.82 17.75 16
14 14.14 3.00 23.00 16.25 .063 1.25 16.75 2.06 2.94 20.25 20
20 20.20 3.75 30.50 23.00 .063 1.38 23.12 2.44 3.69 27.00 24
16 16.16 3.25 25.50 18.50 .063 1.38 19.00 2.19 3.19 22.50 20
22 22.22 4.00 33.00 25.25 .063 1.63 25.25 2.57 3.94 29.25 24
24 24.25 4.19 36.00 27.25 .063 1.62 27.62 2.69 4.13 32.00 24

Dimensions Tolerances Of Super Duplex Steel S32760 Plate Flange

Flange Tolerance Table
D Inside Diameter (I.D.)
  • 10" and smaller: ±1/32" (0.8 mm)
  • 12" thru 18": +1/8" (3.2 mm)
  • 20" and larger: -1/16" (1.6 mm)
K Length of hub
  • 10" and smaller: ±1/16" (1.6 mm)
  • 12" and larger: ±1/8" (3.2 mm)
B Diameter of contact face
  • 1/16" raised face: ±1/32" (0.8 mm)
  • 1/4" RF (Raised Face), T/G (Tongue & Groove), (male & female), (m/f): ±1/64" (0.4 millimeter)
A O.D. (Outside Diameter)
  • When O.D. (Outside Diameter) is 24" or less: ±1/16" (1.6 millimeter)
  • When O.D. (Outside Diameter) is over 24": ±1/8" (3.2 millimeter)
J Diameter of hub at base
  • When hub base is 24" or smaller: ±1/16" (1.6 millimeter)
  • When hub base is over 24": ±1/8" (3.2 millimeter)
P Drilling
  • Circle Bolts: ±1/16" (1.6 mm)
  • Bolts hole spacing: ±1/32" (0.8 mm)
Eccentricity of bolt circle with respect to facing
  • 2 1/2" and smaller ±1/32" (0.8 mm) maximum
  • 3" and larger ±1/16" (1.6 mm) maximum
H Diameter of hub at point of welding
  • 5" and smaller: +3/32" (2.4 mm), -1/32" (0.8 mm)
  • 6" and larger: +5/32" (4.0 mm), -1/32 (0.8 mm)
C Thickness
  • 18" and smaller: ±1/8" (3.2 mm), -0"
  • 20" and larger: ±3/16" (4.8 mm), -0"

Ask Free Sample of Duplex S32760 Flange, SORF Flanges, WNRF Flange, SWRF Flange, BLRF Flange, RTJ Flange Please Call +91 9664408767

Widest Range of Super Duplex Steel S32760 Flange in Mumbai, India.

  • Super Duplex Steel S32760 Flange Price in India
  • UNS S32760 Blind Flange Price
  • ASTM A182 Grade F55 Class 300 Flange
  • UNS S32760 Flange Manufacturer in Mumbai
  • SDSS S32760 Flange Suppliers in Mumbai
  • Duplex S32760 Flange Supplier in India
  • S32760 Super Duplex Steel Flange Stock Near Me
  • Duplex S32760 EN 1092-1 Flange
  • Super Duplex Steel S32760 Flange Suppliers in Mumbai
  • Super Duplex Steel S32760 Flange Manufacturers in Mumbai
  • S32760 Super Duplex Steel Flange Supplier
  • Super Duplex Stainless Steel S32760 Pipe Flange
  • Super Duplex Stainless Steel S32760 Blind Flange Exporters
  • Super Duplex Steel S32760 Flange Exporter
  • 1.4410 Puddle Flange Price
  • ASTM A182 F55 UNS S32760 Flange
  • UNS S32760 Flanges
  • Super Duplex Steel UNS S32760 Slip on Flange
  • Duplex S32760 Blind Flange Dimensions
  • S32760 Duplex Flange Manufacturers in India
  • S32760 SDSS BS 4504 Flanges
  • S32760 Super Duplex Steel Slip On Flange Price
  • SDSS S32760 Flange Price List in India
  • Price of Super Duplex Steel S32760 Flange
  • Super Duplex Steel S32760 Flange Supplier in India
  • S32760 Super Duplex Steel Flange Manufacturers
  • S32760 SDSS GOST 12820-80 Flanges
  • Cost Of S32760 Super Duplex Steel RTJ Flange
  • S32760 Duplex Flange Price Per Kg
  • S32760 SDSS Welding Neck Flange Dimensions
  • Super Duplex Stainless Steel S32760 WNRF Flange
  • S32760 Super Duplex Steel DIN 2527 Flanges
  • 1.4410 Long Welding Neck Flange Exporter
  • Super Duplex Steel UNS S32760 Flanges
  • Super Duplex Steel S32760 Screwed Flange Supplier in India
  • S32760 Super Duplex Stainless Steel Expander Flange
  • Super Duplex Steel S32760 LJFF Flange Sizes
  • Super Duplex Steel S32760 Socket Weld Flange
  • SDSS S32760 SW Flange Price Per Kg in Mumbai
  • S32760 SDSS Weld Neck Flange Application
  • S32760 PN 16 Super Duplex Steel Flanges
  • ASME SA 182 S32760 Super Duplex Steel Nipo Flange
  • ASTM A182 Grade S32760 Duplex BLRF Flange
  • S32760 Super Duplex Stainless Steel LTJ Flange
  • Duplex S32760 SWFF Flange Supplier
  • S32760 Super Duplex Steel PN 10 Flange Stock
  • S32760 Super Duplex Steel SWRTJ Flange Price in India
  • S32760 Super Duplex Stainless Steel Flange Standard Sizes
  • Super Duplex Stainless Steel S32760 Flange in India
  • 1.4410 SOFF Flange Stockists
  • Super Duplex Steel S32760 Male & Female Flange
  • ASTM A182 S32760 Super Duplex Steel Plate Flange

Inspection & Testing of S32760 Super Duplex Steel Pipe Flange

Before being prepared for shipment to the customer, ASTM A182 S32760 Duplex Flanges Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.

Direct-reading Spectrograph

Direct-Reading Spectrograph

UI trasonic flaw detector

UI Trasonic Flaw Detector

Hydrostatic testing machine

Hydrostatic Testing Machine

X-ray detector

X-ray Detector

Magnetic particle detector

Magnetic Particle Detector

Flattening Test

Flattening Test

PMI Testing

PMI Testing

Hardness Test

Hardness Test

Pitting Resistance Test

Pitting Resistance Test

Super Duplex Steel S32760 Flange - Comparing International Standards

USA France Germany Germany Italy Japan Russia Spain Sweden UK European Union
AISI AFNOR DIN 17006 W.N. 17007 UNI JIS GOST UNE SIS BSI EURONORM
UNS32760 X 2 CrNiMoN 22 5 1.4410
best offer & competitive quotation
call us on +91 9664408767

S32760 Super Duplex Steel Flanges Supply in Below Countries

Products We Supplied Description Country
ASME SA182 SDSS S32760 Long Weld Neck Flange Weight 1.4410 2500 LBS LWN Flange Dimensions Portugal, New Zealand, Belgium, Taiwan
SDSS GOST 12820-80 Plate Flanges S32760 SDSS Loose Flanges Czech Republic, Chile, Jordan, Nigeria, Ecuador
S32760 Super Duplex Steel Forged Flanges UNS S32760 Forged Flanges Bulgaria, Nepal, Bhutan, Kuwait
Super Duplex Steel S32760 Raised Face Weld Neck Flange 1.4410 Welding Neck Flange Belarus, Azerbaijan, South Africa, Gambia, Oman
ASTM A182 S32760 Slip On Flange Welding 600 LBS SA182 Gr S32760 SORF Flanges Yemen, Slovakia, Puerto Rico, Romania, Mongolia
S32760 Super Duplex Steel End Blind Flange BS 10 Table F SDSS S32760 Blind Flange Connection Hong Kong, Switzerland, Singapore, Australia
S32760 Super Duplex Steel Socket Weld Flange ANSI B16.47 SDSS 1.4410 Socket Weld Flange Dimensions Estonia, Denmark, Vietnam, Hungary
Super Duplex Steel S32760 Raised Face Slip On Flange UNS S32760 Flat Face Slip On Flange Serbia, Malaysia, Germany, Venezuela

Common Application for S32760 Super Duplex Steel Flanges

Heavy Equipment

Heavy Equipment

Automotive

Automotive

Power Generation

Power Generation

Construction

Construction

Chemical Processing

Chemical

Oil & Gas

Oil & Gas

Shipbuilding

Shipbuilding

Aerospace

Aerospace

Products
Downloads
Duplex Steel & Alloys

Contact us to get a quick quote for your requirement.

+91 9664408767
