| Specifications | ASTM A276, ASTM A479, AMS 5513, AMS 5511, AMS 5647 |
| Dimension Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Bar Diameter | 3 ~ 800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm. Width: 10 to 500mm. |
| Square bar size | 4 to 100mm |
| Rectangular Bars | Size: 33 x 30mm to 295 x 1066mm. Thickness: 3.0 to 12.0mm. |
| Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2 to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients requirements |
| Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex Steel S32750 | 1.4410 | S32750 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S32750 | 7.8 | 0.281 | 1350 | 2460 |
If you are looking for best prices for Super Duplex Steel 2507 Bars, Super Duplex S32750 Rod, SDSS 2507 Flat Bar email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Super Duplex Steel S32750 Round Bar Price | US $999-2500 / Ton |
| 2507 Super Duplex Steel Bar Price | US $1990-3900 / Ton |
| Super Duplex Steel 2507 Square Bar Price | US $800-2100 / Ton |
| Super Duplex S32750 Round Bar Price in India | S $1000.0-3000.0 / Ton |
| Super Duplex Stainless Steel 2507 Hex Bar Price | US $300-2700 / Ton |
| Super Duplex Steel S32750 Rod Rate | US $1000-2500 / Ton |
| Super Duplex Stainless Steel 2507 Triangle Bar Price | US $1500-2600 / Ton |
| 2507 Super Duplex Stainless Steel Rectangular Bar Prices | US $2200-4000 / Ton |
| SDSS S32750 Bright Bar Price List | US $1.2-4.7 / Kilogram |
| Super Duplex Stainless Steel Rod S32750 Price Per KG in India | US $1,600.00-2,200.00 / Ton |
| Type | Sizes in milimeter | Sizes in inches | Tolerance |
| Peeled and Polished | 40.00 - 150.00 | 1.50 - 6.00 | h11, h11-DIN 1013 |
| Cold Drawn and Polish | 3.00 to 75.00 | 1/8 to3.00 | h8 to h11 |
| Cold Drawn and Ground | 10.00 to 75.00 | 5/6 to 2.50 | h8 to h11 |
| Peeled nd Ground | 20.00 - 50.00 | 3/4 - 2.00 | h9 to h11 |
Super Duplex S32750 Round Bars Standard lengths of 2000 mm up to 6000 mm.
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
| Diameter | Weight Chart | Dia | Weight Chart |
| (mm) | per metre (kg) | (in) | per metre (kg) |
| 3mm | 0.06 | 1/8" | 0.06 |
| 4mm | 0.10 | 3/16" | 0.14 |
| 5mm | 0.16 | 1/4" | 0.25 |
| 6mm | 0.22 | 5/16" | 0.39 |
| 7mm | 0.30 | 3/8" | 0.56 |
| 8mm | 0.40 | 7/16" | 0.77 |
| 10mm | 0.62 | 1/2" | 1.00 |
| 12mm | 0.89 | 9/16" | 1.22 |
| 14mm | 1.22 | 5/8" | 1.56 |
| 15mm | 1.40 | 11/16" | 1.89 |
| 16mm | 1.59 | 3/4" | 2.25 |
| 18mm | 2.01 | 7/8" | 3.07 |
| 20mm | 2.48 | 1" | 4.03 |
| 22mm | 3.00 | ||
| 24mm | 3.57 | ||
| 25mm | 3.88 |
| Diameter or Width (mm) |
Weight per meter | Sectional Area | Perimeter | |||
| Square (kg) |
Round (kg) |
Square (cm²) |
Round (cm²) |
Square (cm) |
Round (cm) |
|
| 5.0 | 0.20 | 0.15 | 0.25 | 0.20 | 2.0 | 1.57 |
| 5.5 | 0.24 | 0.19 | 0.30 | 0.24 | 2.2 | 1.78 |
| 6.0 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 7.0 | 0.38 | 0.30 | 0.49 | 0.38 | 2.8 | 2.20 |
| 8.0 | 0.50 | 0.39 | 0.64 | 0.50 | 3.2 | 2.51 |
| 9.0 | 0.64 | 0.50 | 0.81 | 0.64 | 3.6 | 2.83 |
| 10 | 0.73 | 0.63 | 1.00 | 0.79 | 4.0 | 3.14 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.40 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 18 | 2.54 | 2.00 | 3.24 | 2.54 | 7.2 | 5.65 |
| 20 | 3.14 | 2.47 | 4.00 | 3.14 | 8.0 | 6.28 |
| 22 | 3.80 | 2.98 | 4.84 | 3.80 | 8.8 | 6.91 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10.0 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.80 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16.00 | 12.57 | 16.0 | 12.57 |
| 45 | 15.90 | 12.49 | 20.25 | 15.90 | 18.0 | 14.14 |
| 50 | 19.62 | 15.41 | 25.00 | 19.64 | 20.0 | 15.71 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64.00 | 50.27 | 32.0 | 25.13 |
Ask Free Sample of Super Duplex Steel 2507 Bar, Rods, Round Bar Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A276 S32750 Super Duplex Steel Bars Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Compression Test
Bending Test
Impact Test
Torsion Test
Tensile Test
Brinell/Rockwell Hardness Test
| CD | Cold drawn | P | Polished |
| CG | Centreless ground | HF | Hot finished |
| BD | Bright drawn | SRE | Slit rolled edge |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| ST | Smooth turned | PR | Peeled and reeled |
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| UNS32750 | X 2 CrNiMoN 22 5 | 1.4410 |
| Products We Supplied | Description | Country |
| ASME SA276 2507 Super Duplex Steel Bars | 1.4410 Cold Rolled Bars | Portugal, New Zealand, Belgium, Taiwan |
| S32750 Super Duplex Steel Square Bar Weight | 8mm Super Duplex Steel 2507 Square Sar | Denmark, Estonia, Vietnam, Hungary |
| Super Duplex Steel S32750 Hex Bar Sizes in MM | Super Duplex 2507 Hexagonal Bar | Yemen, Slovakia, Mongolia, Puerto Rico, Romania |
| ASTM A276 Super Duplex Stainless Steel S32750 Rods | SAF 2507 3mm to 50mm Rods | Gambia, Belarus, Azerbaijan, South Africa, Oman |
| Super Duplex Steel S32750 Rectangular Bars | 3.0 to 12.0mm Rhickness SDSS 2507 Rectangular Bar | Czech Republic, Nigeria, Ecuador, Jordan, Chile |
| S32750 Super Duplex Steel Rectangular Bar | SAF 2507 Cold Drawn Rectangular Bar | Hong Kong, Singapore, Australia, Switzerland |
| Super Duplex Stainless Steel 2507 Round Bars | UNS S32750 Hot Rolled Rods Supply | Serbia, Venezuela, Germany, Malaysia |
| 2507 Super Duplex Stainless Steel Polished Bars | Polished UNS S32750 Bars | Nepal, Kuwait, Bhutan, Bulgaria |
Power Generation
Construction
Shipbuilding
Aerospace
Heavy Equipment
Automotive
Chemical
Oil & Gas
