| Specifications | ASTM A182 / ASME SA182 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Types | Socketweld Fittings, Screwed-Threaded Fittings |
| Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Thread | NPT, BSPT, BSPP |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel S32205 | 1.4462 | S32205 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| Duplex 2205 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 21.0 – 23.0 | 2.50 – 3.50 | 4.50 – 6.50 | 0.8 – 0.20 | 63.54 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| Duplex 2205 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
If you are looking for best prices for Duplex Steel 2205 Forged Fittings, UNS S32205 BSP Elbow, 2205 Duplex Union email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Custom Size 2000 LB, 1 1/2 Inch DSS 2205 Socket Weld Elbow Price | US $ 0.5-1.0 / Piece |
| ASME B16.11 Duplex 2205 Forged Socket weld Fittings Price | US $ 1.00-4000.0 / Piece |
| 2205 Duplex Steel Threaded Hex Nipple Price List | US $ 3.0-50.0 / Piece |
| NPS 1/2 to 2 Duplex Steel 2205 Union Male x Female Price | US $ 2.5-60.0 / Piece |
| ANSI B16.11 2205 Duplex Steel 6 inch Forged Cap Price | US $ 1-2000 / Piece |
| Duplex Stainless Steel S32205 BSP Fittings | US $ 1.2 / Piece |
| ASTM A182 Duplex 2205 Forged Pipe Fittings Price | US $ 00.1-40 / Piece |
| ASME SA 182 S32205 Duplex Steel Screwed Pipe Fittings 150lb Price List | US $ 3.0-50.0 / Piece |
| 2205 Duplex Steel End Cap Price List | US $ 3.87 / Piece |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A |
Center to End 45 Deg Elbow C |
O.D. of Band H |
Min. Wall Thick. G |
Length of Thread. Minimum (1) |
|||||||||
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| DN | NPS | End to End Couplings W |
End to End Caps P |
O.D. D | End Wall Thick. G Minimum |
Length of Thread. Minimum (1) |
||||
| Class 3000&Class 6000 | Class 3000 | Class 6000 | Class 3000 | Class 6000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 32 | 19 | … | 16 | 22 | 4.8 | … | 6.4 | 6.7 |
| 8 | 1/4 | 35 | 25 | 27 | 19 | 25 | 4.8 | 6.4 | 8.1 | 10.2 |
| 10 | 3/8 | 38 | 25 | 27 | 22 | 32 | 4.8 | 6.4 | 9.1 | 10.4 |
| 15 | 1/2 | 48 | 32 | 33 | 28 | 38 | 6.4 | 7.9 | 10.9 | 13.6 |
| 20 | 3/4 | 51 | 37 | 38 | 35 | 44 | 6.4 | 7.9 | 12.7 | 13.9 |
| 25 | 1 | 60 | 41 | 43 | 44 | 57 | 9.7 | 11.2 | 14.7 | 17.3 |
| 32 | 1-1/4 | 67 | 44 | 46 | 57 | 64 | 9.7 | 11.2 | 17.0 | 18.0 |
| 40 | 1-1/2 | 79 | 44 | 48 | 64 | 76 | 11.2 | 12.7 | 17.8 | 18.4 |
| 50 | 2 | 86 | 48 | 51 | 76 | 92 | 12.7 | 15.7 | 19.0 | 19.2 |
| 65 | 2-1/2 | 92 | 60 | 64 | 92 | 108 | 15.7 | 19.0 | 23.6 | 28.9 |
| 80 | 3 | 108 | 65 | 68 | 108 | 127 | 19.0 | 22.4 | 25.9 | 30.5 |
| 100 | 4 | 121 | 68 | 75 | 140 | 159 | 22.4 | 28.4 | 27.7 | 33.0 |
| ASME B16.11 Pressure-Temperature | |||||
| Temperature | Class | ||||
| 150 | 300 | ||||
| 1/4 - 1 inch. | 1 1/4 - 2 inch. | 2 1/2 - 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | - | 935 | 750 | 560 |
| 450 | 232 | - | 725 | 600 | 475 |
| 500 | 260 | - | 510 | 450 | 385 |
| 550 | 288 | - | 300 | 300 | 300 |
| ANSI B16.11 American Standard Dimensional Tolerances | ||
| "A" - Threaded Center To Bottom | For Size 1/8" And 1/4" |
± 0.03" |
| 3/8", 1/2" And 3/4" | ± 0.06" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.08" | |
| 2-1/2", 3", And 4" | ± 0.10" | |
| "B" - Threaded Bore Diameter | For Size 1-1/2" And Smaller |
+ 0.020" - 0.000" |
| 2", 2-1/2", 3" And 4" | + 0.025" - 0.000" |
|
| "C" - Threaded Wall Thick. | Min. = 1.09 T (But Not Less Than 5/32") T = Wall Thickness Of Nominal Pipe Sizes |
|
| "D" - Bore Diameter Of Pipe Fitting | For Size 2" And Smaller |
± 0.030" |
| 2-1/2", 3" And 4" | ± 0.060" | |
| "E" - Threadeds- Bottom To Bottom - Full Couplings | For Size 1/8" And 1/4" |
± 0.06" |
| 3/8", 1/2" And 3/4" | ± 0.12" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.16" | |
| 2-1/2", 3", And 4" | ± 0.20" | |
| "F" - Bottom Of Threaded To Opposite Face - ANSI B16.11 Half Couplings | For Size 1/8" And 1/4" |
± 0.03" |
| 3/8", 1/2" And 3/4" | ± 0.06" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.08" | |
| 2-1/2", 3", And 4" | ± 0.10" | |
| "G" - Gap Of Welding | Approx. 0.06" Before Welding Recommended Gap |
|
| "H" - Min. Flat | Min. Flat = 0.75 X Min. Threaded Wall Thick. |
|
Ask Free Sample of Duplex Steel 2205 Forged Elbow, Tee, Coupling, Union Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A182 Duplex Stainless Steel 2205 Threaded Forged Fittings Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Hardness Test
PMI Testing
Ultrasonic Testing
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| UNS S32205 | X 2 CrNiMoN 22 5 | 1.4462 |
| Products We Supplied | Description | Country |
| Duplex Steel 2205 Forged 90° Elbow | UNS S32205 2000 LB, 1 1/2 Inch 90 Deg Elbow Supply | UAE, Romania, Europe, Norway |
| Duplex 2205 Forged Unequal Tee | 1/2 Inch, ASME B16.11 DSS 2205 Socket Weld Tee | Thailand, Indonesia, Saudi Arabia, Vietnam |
| Duplex Stainless Steel 2205 Threaded Equal Tee | 4 Inch UNS S32205 NPT Threaded Tee | Nigeria, Ellington -United States, Canada, Australia |
| Duplex Steel 2205 Forged Socket Weld Elbow | 3 Inch ASME B16.11 DSS 2205 SW Elbow | Taiwan, Kuwait, Philippines, South Africa |
| ASTM A182 Duplex Steel 2205 Socket weld Reducing Tee | 1.4462 CL3000, DN25, B16.11, Socket Reducing Tee | Egypt, Malaysia, rance, Mexico |
| DSS S32205 Forged Pipe Coupling | 3000#, 4 Inch, Threaded SAF 2205 Pipe Coupling | UK, Jordan, Belgium, Netherlands, Venezuela |
| Duplex Steel 2205 NPT Threaded Pipe Fittings | 8 Inch UNS S32205 Forged Threaded Fittings | Ukraine, Mongolia, Colombia, Tunisia |
| Duplex Stainless Steel 2205 Socket weld Half Coupling | 2-1/2 INCH 3000 LB 1/2 DSS 2205 SW Half Coupling | Morocco, Canada, Turkey, Egypt, Germany |
| Duplex Stainless Steel 2205 Screwed Bushing | 1/2 inch ASME SA182 Duplex 2205 Threaded Bushing | Uruguay, Costa Rica, Singapore, Finland, Maldives |
