| Standard | ASTM A479 / ASME SA479 |
| Bolt / Screw Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Nuts Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Washers Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Machine Screws Size | M1.6 – M12 |
| Self Tapping Screw Size | No.2 – No. 14 |
| Length | 3 mm to 200 mm |
| Threads | UNF, BSW, BSF, METRIC, UNC, or as required |
| Fasteners |
|
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production Process | M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| STANDARD | WERKSTOFF NR. | UNS |
| Duplex Steel | 1.4462 | S31803 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S31803 | 0.030 max | 2.00 max | 1.00 max | 0.030 max | 0.020 max | 22.0 – 23.0 | 3.0 – 3.5 | 4.50 – 6.50 | 0.14 – 0.20 | 63.72 min |
| Grades | Density (g/cm 3) | Density (lb/in 3) | Melting Point (°C) | Melting Point (°F) |
| S31803 | 7.805 | 0.285 | 1420 – 1465 | 2588 – 2669 |
If you are looking for best prices for Duplex Steel S31803 Fasteners, Duplex S31803 Stud Bolt, S31803 Duplex Fasteners email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Duplex S31803 Nut Bolt Price Per Kg | US $1.99-200 / Kg |
| ASTM A479 Hexagon Head Screw Duplex Steel S31803 | US $1290-4900 / Ton |
| Cost Per Kg of Duplex Steel S31803 Heavy Hex Nuts | US $99-1100 / Kg |
| Duplex Stainless Steel S31803 Washer Price | S $1.00-900.0 / Kg |
| S31803 Duplex Steel Self Locking Nuts Price Per Kg | US $190-1990 / Ton |
| Duplex S31803 Heavy Hex Bolt price | US $1000-4500 / Ton |
| Duplex S31803 Anchor Fasteners Price List | US $1500-2600 / Ton |
| S31803 Duplex Steel Bolt Price List | US $2200-4000 / Ton |
| Duplex Stainless Steel S31803 Socket Head Screw Price | US $1.2-3.7 / Kilogram |
| UNS S31803 Allen Cap Screw Price | US $1,100.00-2,100.00 / Ton |
| Size | Nominal (Major) Diameter [in] |
Coarse Thread (UNC) | Fine Thread (UNF) | ||||
| Threads Per Inch |
Tensile Stress Area [in2] |
Minor Area [in2] |
Threads Per Inch |
Tensile Stress Area [in2] |
Minor Area [in2] |
||
| #0 | 0.0600 | --- | --- | --- | 80 | 0.00180 | 0.00151 |
| #2 | 0.0860 | 56 | 0.00370 | 0.00310 | 64 | 0.00394 | 0.00339 |
| #4 | 0.1120 | 40 | 0.00604 | 0.00496 | 48 | 0.00661 | 0.00566 |
| #5 | 0.1250 | 40 | 0.00796 | 0.00672 | 44 | 0.00830 | 0.00716 |
| #6 | 0.1380 | 32 | 0.00909 | 0.00745 | 40 | 0.01015 | 0.00874 |
| #8 | 0.1640 | 32 | 0.0140 | 0.01196 | 36 | 0.01474 | 0.01285 |
| #10 | 0.1900 | 24 | 0.0175 | 0.01450 | 32 | 0.0200 | 0.0175 |
| 1/4" | 0.2500 | 20 | 0.0318 | 0.0269 | 28 | 0.0364 | 0.0326 |
| 5/16" | 0.3125 | 18 | 0.0524 | 0.0454 | 24 | 0.0580 | 0.0524 |
| 3/8" | 0.3750 | 16 | 0.0775 | 0.0678 | 24 | 0.0878 | 0.0809 |
| 7/16" | 0.4375 | 14 | 0.1063 | 0.0933 | 20 | 0.1187 | 0.1090 |
| 1/2" | 0.5000 | 13 | 0.1419 | 0.1257 | 20 | 0.1599 | 0.1486 |
| 9/16" | 0.5625 | 12 | 0.182 | 0.162 | 18 | 0.203 | 0.189 |
| 5/8" | 0.6250 | 11 | 0.226 | 0.202 | 18 | 0.256 | 0.240 |
| 3/4" | 0.7500 | 10 | 0.334 | 0.302 | 16 | 0.373 | 0.351 |
| 7/8" | 0.8750 | 9 | 0.462 | 0.419 | 14 | 0.509 | 0.480 |
| 1" | 1.0000 | 8 | 0.606 | 0.551 | 12 | 0.663 | 0.625 |
| 1-1/8" | 1.1250 | 7 | 0.763 | 0.693 | 12 | 0.856 | 0.812 |
| 1-1/4" | 1.2500 | 7 | 0.969 | 0.890 | 12 | 1.073 | 1.024 |
| 1-3/8" | 1.3750 | 6 | 1.155 | 1.054 | 12 | 1.315 | 1.260 |
| 1-1/2" | 1.5000 | 6 | 1.405 | 1.294 | 12 | 1.581 | 1.521 |
| 1-3/4" | 1.7500 | 5 | 1.90 | 1.74 | --- | --- | --- |
| 2" | 2.0000 | 4.5 | 2.50 | 2.30 | --- | --- | --- |
The following table of clearance holes was adapted from ASME B18.2.8. The minimum hole diameters are given.
| Bolt Size | Bolt Dia. [in] | Normal Fit [in] | Close Fit [in] | Loose Fit [in] |
| #0 | 0.0600 | 0.076 | 0.067 | 0.094 |
| #2 | 0.0860 | 0.102 | 0.094 | 0.116 |
| #4 | 0.1120 | 0.128 | 0.120 | 0.144 |
| #5 | 0.1250 | 0.156 | 0.141 | 0.172 |
| #6 | 0.1380 | 0.170 | 0.154 | 0.185 |
| #8 | 0.1640 | 0.196 | 0.180 | 0.213 |
| #10 | 0.1900 | 0.221 | 0.206 | 0.238 |
| 1/4" | 0.2500 | 0.281 | 0.266 | 0.297 |
| 5/16" | 0.3125 | 0.344 | 0.328 | 0.359 |
| 3/8" | 0.3750 | 0.406 | 0.391 | 0.422 |
| 7/16" | 0.4375 | 0.469 | 0.453 | 0.484 |
| 1/2" | 0.5000 | 0.562 | 0.531 | 0.609 |
| 5/8" | 0.6250 | 0.688 | 0.656 | 0.734 |
| 3/4" | 0.7500 | 0.812 | 0.781 | 0.906 |
| 7/8" | 0.8750 | 0.938 | 0.906 | 1.031 |
| 1" | 1.0000 | 1.094 | 1.031 | 1.156 |
| 1-1/8" | 1.1250 | 1.219 | 1.156 | 1.312 |
| 1-1/4" | 1.2500 | 1.344 | 1.281 | 1.438 |
| 1-3/8" | 1.3750 | 1.500 | 1.438 | 1.609 |
| 1-1/2" | 1.5000 | 1.625 | 1.562 | 1.734 |
The following table of hex nut dimensions was adapted from ASME B18.2.2, Table 1-1, "Dimensions of Square and Hex Machine Screw Nuts." This table is used for smaller size hardware.
| Size | Nominal (Major) Diameter [in] |
Width Across Flats | Thickness | ||
| Nominal [in] | Minimum [in] | Minimum [in] | Maximum [in] | ||
| #0 | 0.060 | 5/32"(0.156) | 0.150 | 0.043 | 0.050 |
| #2 | 0.086 | 3/16"(0.188) | 0.180 | 0.057 | 0.066 |
| #4 | 0.112 | 1/4"(0.250) | 0.241 | 0.087 | 0.098 |
| #6 | 0.138 | 5/16"(0.312) | 0.302 | 0.102 | 0.114 |
| #8 | 0.164 | 11/32"(0.344) | 0.332 | 0.117 | 0.130 |
| #10 | 0.190 | 3/8"(0.375) | 0.362 | 0.117 | 0.130 |
| 1/4" | 0.250 | 7/16"(0.438) | 0.423 | 0.178 | 0.193 |
| 5/16" | 0.312 | 9/16"(0.562) | 0.545 | 0.208 | 0.225 |
| 3/8" | 0.375 | 5/8"(0.625) | 0.607 | 0.239 | 0.257 |
The following table of hex nut dimensions was adapted from ASME B18.2.2, Table 4, "Dimensions of Hex Nuts and Hex Jam Nuts."
| Size | Nominal (Major) Diameter [in] |
Width Across Flats | Thickness | ||
| Minimum [in] | Maximum [in] | Minimum [in] | Maximum [in] | ||
| 1/4" | 0.2500 | 0.428 | 0.438 | 0.212 | 0.226 |
| 5/16" | 0.3125 | 0.489 | 0.500 | 0.258 | 0.273 |
| 3/8" | 0.3750 | 0.551 | 0.563 | 0.320 | 0.337 |
| 7/16" | 0.4375 | 0.675 | 0.688 | 0.365 | 0.385 |
| 1/2" | 0.5000 | 0.736 | 0.750 | 0.427 | 0.448 |
| 9/16" | 0.5625 | 0.861 | 0.875 | 0.473 | 0.496 |
| 5/8" | 0.6250 | 0.922 | 0.938 | 0.535 | 0.559 |
| 3/4" | 0.7500 | 1.088 | 1.125 | 0.617 | 0.665 |
| 7/8" | 0.8750 | 1.269 | 1.312 | 0.724 | 0.776 |
| 1" | 1.0000 | 1.450 | 1.500 | 0.831 | 0.887 |
| 1-1/8" | 1.1250 | 1.631 | 1.688 | 0.939 | 0.999 |
| 1-1/4" | 1.2500 | 1.812 | 1.875 | 1.030 | 1.094 |
| 1-3/8" | 1.3750 | 1.994 | 2.062 | 1.138 | 1.206 |
| 1-1/2" | 1.5000 | 2.175 | 2.250 | 1.245 | 1.317 |
| 1-5/8" | 1.6250 | 2.350 | 2.430 | 1.364 | 1.416 |
| 1-3/4" | 1.7500 | 2.538 | 2.625 | 1.460 | 1.540 |
| 1-7/8" | 1.8750 | 2.722 | 2.813 | 1.567 | 1.651 |
| 2" | 2.0000 | 2.900 | 3.000 | 1.675 | 1.763 |
The following table of flat washer dimensions was adapted from ASME B18.21.1, Table 11 for Type A Plain Washers. Type A washers come in 2 series: Narrow and Wide.
| Size | Basic Dia. [in] | Series | Inner Dia, Basic [in] |
Outer Dia, Basic [in] |
Thickness, Basic [in] |
| #0 | 0.0600 | --- | 0.078 | 0.188 | 0.020 |
| #2 | 0.0860 | --- | 0.094 | 0.250 | 0.020 |
| #4 | 0.1120 | --- | 0.125 | 0.312 | 0.032 |
| #6 | 0.1380 | --- | 0.156 | 0.375 | 0.049 |
| #8 | 0.1640 | --- | 0.188 | 0.438 | 0.049 |
| #10 | 0.1900 | --- | 0.219 | 0.500 | 0.049 |
| 1/4" | 0.2500 | Narrow | 0.281 | 0.625 | 0.065 |
| 1/4" | 0.2500 | Wide | 0.312 | 0.734 | 0.065 |
| 5/16" | 0.3125 | Narrow | 0.344 | 0.688 | 0.065 |
| 5/16" | 0.3125 | Wide | 0.375 | 0.875 | 0.083 |
| 3/8" | 0.3750 | Narrow | 0.406 | 0.812 | 0.065 |
| 3/8" | 0.3750 | Wide | 0.438 | 1.000 | 0.083 |
| 7/16" | 0.4375 | Narrow | 0.469 | 0.922 | 0.065 |
| 7/16" | 0.4375 | Wide | 0.500 | 1.250 | 0.083 |
| 1/2" | 0.5000 | Narrow | 0.531 | 1.062 | 0.095 |
| 1/2" | 0.5000 | Wide | 0.562 | 1.375 | 0.109 |
| 9/16" | 0.5625 | Narrow | 0.594 | 1.156 | 0.095 |
| 9/16" | 0.5625 | Wide | 0.625 | 1.469 | 0.109 |
| 5/8" | 0.6250 | Narrow | 0.656 | 1.312 | 0.095 |
| 5/8" | 0.6250 | Wide | 0.688 | 1.750 | 0.134 |
| 3/4" | 0.7500 | Narrow | 0.812 | 1.469 | 0.134 |
| 3/4" | 0.7500 | Wide | 0.812 | 2.000 | 0.148 |
| 7/8" | 0.8750 | Narrow | 0.938 | 1.750 | 0.134 |
| 7/8" | 0.8750 | Wide | 0.938 | 2.250 | 0.165 |
| 1" | 1.0000 | Narrow | 1.062 | 2.000 | 0.134 |
| 1" | 1.0000 | Wide | 1.062 | 2.500 | 0.165 |
| 1-1/8" | 1.1250 | Narrow | 1.250 | 2.250 | 0.134 |
| 1-1/8" | 1.1250 | Wide | 1.250 | 2.750 | 0.165 |
| 1-1/4" | 1.2500 | Narrow | 1.375 | 2.500 | 0.165 |
| 1-1/4" | 1.2500 | Wide | 1.375 | 3.000 | 0.165 |
| 1-3/8" | 1.3750 | Narrow | 1.500 | 2.750 | 0.165 |
| 1-3/8" | 1.3750 | Wide | 1.500 | 3.250 | 0.180 |
| 1-1/2" | 1.5000 | Narrow | 1.625 | 3.000 | 0.165 |
| 1-1/2" | 1.5000 | Wide | 1.625 | 3.500 | 0.180 |
| 1-5/8" | 1.6250 | --- | 1.750 | 3.750 | 0.180 |
| 1-3/4" | 1.7500 | --- | 1.875 | 4.000 | 0.180 |
| 1-7/8" | 1.8750 | --- | 2.000 | 4.250 | 0.180 |
| 2" | 2.0000 | --- | 2.125 | 4.500 | 0.180 |
Ask Free Sample of Duplex Steel S31803 Fastener, Bolts, Nuts, Washer. Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A479 Duplex Steel S31803 Fasteners Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Shear Test
Fatigue Test
Biaxial Test
Creep Test
Drop Weight Test
Flexure Test
| Powder coating | Zinc and yellow plated |
| Zinc and de-embrittled | Stayblack finish |
| Sherardised | Nickel |
| Green chromate | Geomet |
| Galvanised | Electro brass plated |
| Chrome | Chemical black |
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| UNS31803 | X 2 CrNiMoN 22 5 | 1.4462 |
| Products We Supplied | Description | Country |
| Duplex Steel S31803 Fasteners | UNS S31803 U Bolts Supply | Malaysia, Venezuela, Serbia, Germany |
| ASTM A479 DSS Duplex Fasteners | Duplex Steel 1.4462 Nut Bolt Weight Chart In Kg | Azerbaijan, Oman, Gambia, South Africa, Belarus |
| Duplex Steel S31803 Bolts and Nuts Price List | S31803 Duplex Stainless Steel Eye Bolts | Romania, Puerto Rico, Slovakia, Yemen, Mongolia |
| S31803 Duplex Fasteners Manufacturers | 1.4462 Double Ended Studs In India | Switzerland, Singapore, Australia, Hong Kong |
| ASME SA479 S31803 Duplex Steel Fasteners In India | Duplex Stainless Steel S31803 Acorn Nuts Manufacturers In India | Belgium, Taiwan, New Zealand, Portugal |
| Duplex Steel S31803 Fastener | S31803 Duplex Nyloc Nuts Manufacturers In India | Nigeria, Ecuador, Chile, Czech Republic, Jordan |
| Duplex S31803 Bolt Torque Chart | UNS S31803 Carriage Bolts Near Me | Kuwait, Bhutan, Nepal, Bulgaria |
| Duplex Steel S31803 Spring Washer | S31803 Duplex Steel Flat Washers | Estonia, Denmark, Hungary, Vietnam |
Heavy Equipment
Automotive
Chemical
Power Generation
Shipbuilding
Construction
Aerospace
Oil & Gas
