| Specifications | ASTM B622, ASTM B619 / ASME SB622, ASME SB619 |
| Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) | EN 10258/ DIN 59381) EN 10151 EN 10088 |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| STANDARD | WERKSTOFF NR. | UNS | JIS | GOST | EN | OR |
| Hastelloy C22 | 2.4602 | N06022 | NW 6022 | ХН65МВУ | NiCr21Mo14W | - |
| Grade | C | Mn | Si | S | Co | Ni | Cr | Fe | Mo | P |
| Hastelloy C22 | 0.010 max | 0.50 max | 0.08 max | 0.02 max | 2.50 max | 50.015 min* | 20.00 – 22.50 | 2.00 – 6.00 | 12.50 – 14.50 | 0.02 max |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Hastelloy C22 | 8.69 g/cm3 | 1399 °C (2550 °F) | Psi – 1,00,000 , MPa – 690 | Psi – 45000 , MPa – 310 | 45 % |
If you are looking for best prices for Hastelloy Alloy C22 Strip, Nickel Alloy C22 Foil, Alloy C22 Sheet email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Hastelloy C22 Sheet Price | US $1300-1900 / Ton |
| Hastelloy® Alloy C22 Sheet Price | US $1000-3000 / Ton |
| C22 Hastelloy® Alloy Plate Price Per KG | US $1000-2500 / Ton |
| 6mm ASTM BB622 UNS N06022 Sheet Price | S $1000.0-1000.0 / Ton |
| Hastelloy C22 Sheet Price Per KG | US $2000-2500 / Ton |
| Nickel Alloy C22 Sheet Price Per KG | US $1300-3700 / Ton |
| Hastelloy® Alloy C22 Plate Price | US $1500-2500 / Ton |
| Polished Nickle Alloy C22 Plate Price List | US $1200-5000 / Ton |
| Alloy C22 Shim Sheet Price List | US $1.3-2.7 / Kilogram |
| 10mm Thick Hastelloy Alloy C22 Plate Price | US $2,600.00/ Ton |
| Thickness | Thickness | Size Range | Surface Area per Unit weight | Approx Weight per Sheet | ||
| inches | mm | lbs/ft² | kg/m² | lbs | kg | |
|---|---|---|---|---|---|---|
| 0.015 | 0.381 | 36 x 96 | 0.630 | 3.07566 | 15.12 | 6.84936 |
| 0.015 | 0.381 | 36 x 120 | 0.630 | 3.07566 | 18.90 | 8.5617 |
| 0.0178 | 0.45212 | 36 x 96 | 0.756 | 3.690792 | 18.15 | 8.22195 |
| 0.0178 | 0.45212 | 36 x 120 | 0.756 | 3.690792 | 22.68 | 10.27404 |
| 0.0178 | 0.45212 | 48 x 96 | 0.756 | 3.690792 | 24.19 | 10.95807 |
| 0.0178 | 0.45212 | 48 x 120 | 0.756 | 3.690792 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 30 x 96 | 1.008 | 4.921056 | 20.16 | 9.13248 |
| 0.0235 | 0.5969 | 30 x 120 | 1.008 | 4.921056 | 25.20 | 11.4156 |
| 0.0235 | 0.5969 | 36 x 96 | 1.008 | 4.921056 | 24.19 | 10.95807 |
| 0.0235 | 0.5969 | 36 x 120 | 1.008 | 4.921056 | 30.24 | 13.69872 |
| 0.0235 | 0.5969 | 36 x 144 | 1.008 | 4.921056 | 36.29 | 16.43937 |
| 0.0235 | 0.5969 | 48 x 96 | 1.008 | 4.921056 | 32.26 | 14.61378 |
| 0.0235 | 0.5969 | 48 x 120 | 1.008 | 4.921056 | 40.32 | 18.26496 |
| 0.0235 | 0.5969 | 48 x 144 | 1.008 | 4.921056 | 48.39 | 21.92067 |
| 0.0291 | 0.73914 | 30 x 96 | 1.260 | 6.15132 | 25.20 | 11.4156 |
| 0.0291 | 0.73914 | 30 x 120 | 1.260 | 6.15132 | 31.50 | 14.2695 |
| 0.0291 | 0.73914 | 36 x 96 | 1.260 | 6.15132 | 30.24 | 13.69872 |
| 0.0291 | 0.73914 | 36 x 120 | 1.260 | 6.15132 | 37.80 | 17.1234 |
| 0.0291 | 0.73914 | 36 x 144 | 1.260 | 6.15132 | 45.37 | 20.55261 |
| 0.0291 | 0.73914 | 48 x 96 | 1.260 | 6.15132 | 40.32 | 18.26496 |
| 0.0291 | 0.73914 | 48 x 120 | 1.260 | 6.15132 | 50.41 | 22.83573 |
| 0.0291 | 0.73914 | 48 x 144 | 1.260 | 6.15132 | 60.49 | 27.40197 |
| 0.0355 | 0.9017 | 30 x 96 | 1.512 | 7.381584 | 30.24 | 13.69872 |
| 0.0355 | 0.9017 | 30 x 120 | 1.512 | 7.381584 | 37.80 | 17.1234 |
| 0.0355 | 0.9017 | 36 x 96 | 1.512 | 7.381584 | 36.29 | 16.43937 |
| Weight per | Size | Size | Weight per | ||||
| Sheets (Kg) | (mm) | (mm) | Sheets (Kg) | ||||
| 12.8 | 2500 x | 1250 x | 0.5 | 2000 x | 1000 x | 1.5 | 24.6 |
| 8.2 | 2000 x | 1000 x | 0.5 | 3000 x | 1500 x | 1.2 | 44.2 |
| 17.9 | 2500 x | 1250 x | 0.7 | 3000 x | 1500 x | 1.5 | 55.3 |
| 13.1 | 2000 x | 1000 x | 0.8 | 2000 x | 1000 x | 2.0 | 32.7 |
| 11.5 | 2000 x | 1000 x | 0.7 | 2500 x | 1250 x | 1.5 | 38.4 |
| 14.7 | 2000 x | 1000 x | 0.9 | 3000 x | 1500 x | 2.0 | 73.7 |
| 20.5 | 2500 x | 1250 x | 0.8 | 2500 x | 1250 x | 2.0 | 51.2 |
| 33.2 | 3000 x | 1500 x | 0.9 | 2500 x | 1250 x | 2.5 | 63.9 |
| 36.8 | 3000 x | 1500 x | 1.0 | 2500 x | 1250 x | 3.0 | 77.5 |
| 23.0 | 2500 x | 1250 x | 0.9 | 2000 x | 1000 x | 2.5 | 40.9 |
| 25.6 | 2500 x | 1250 x | 1.0 | 2000 x | 1000 x | 3.0 | 49.6 |
| 16.4 | 2000 x | 1000 x | 1.0 | 3000 x | 1500 x | 2.5 | 92.1 |
| 19.6 | 2000 x | 1000 x | 1.2 | 3000 x | 1500 x | 3.0 | 112.0 |
| 30.7 | 2500 x | 1250 x | 1.2 | - | - | - | - |
Ask Free Sample of Hastelloy C22 Sheet, Plate, Coil, Strip, Flat Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM B622 Alloy C22 Plates Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
PMI Testing
Hydrostatic Test
Radiography Test
| Surface finish | Thickness (mm) | Width (max mm) |
| 2B – Cold rolled, heat treated, pickled, skin passed Sheet | 0.25–8.0 | 2032 |
| 2D – Cold rolled, heat treated, pickled Sheet | 0.4–6.35 | 1524 |
| 2E – Cold rolled, heat treated, mechanically descaled plate | 0.4–8.0 | 2032 |
| 2R – Cold rolled, bright annealed plate | 0.25–3.5 | 1524 |
| 2H – Work hardened plate | 0.4–6.35 | 1524 |
| Polished, brushed plate | 0.5–4.0 | 1524 |
| Surface finish | Gauge (in) | Width (max in) |
| 2B – Cold rolled, heat treated, pickled, skin passed Plate | 10–24 | 72* |
| 2D – Cold rolled, heat treated, pickled plate | 12–24 | 60 |
| Polished Sheet (not brushed) | 11–24 | 60 |
| EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Finland SFS |
Austria ONORM |
Russia GOST |
| NiCr21Mo14W | C22 | 2.4602 | NW 6022 | NU-30M | - | - | - | - | - | - | - | - | - |
| Products We Supplied | Description | Country |
| 3mm Hastelloy alloy C22 Sheet | UNS N06022 Hot Rolled Sheets Supply | Germany, Venezuela, Serbia, Malaysia |
| ASTM B622 Hastelloy C22 Sheets | 6mm Thick Hastelloy 2.4602 Sheet | Gambia, South Africa, Belarus, Azerbaijan, Oman |
| Nickel Alloy C22 Perforated Sheets | 0.35mm Cold Rolled UNS N06022 Sheets | Puerto Rico, Mongolia, Yemen, Romania, Slovakia |
| ASTM B622 Hastelloy Alloy C22 Coils | 2.4602 Cold Rolled Slitting Coils | Portugal, Taiwan, New Zealand, Belgium |
| C22 Hastelloy Alloy HR Plate | 10mm Thick Hastelloy C22 Plate | Czech Republic, Ecuador, Jordan, Chile, Nigeria |
| Hastelloy Alloy C22 Polished Plates | 16 Gauge UNS N06022 Plates | Nepal, Bhutan, Kuwait, Bulgaria |
| Hastelloy Alloy C22 3/16" Plate | 8k Mirror Finish Hastelloy C22 Plate | Denmark, Hungary, Vietnam, Estonia |
Oil & Gas
Chemical
Power Generation
Aerospace
Heavy Equipment
Automotive
Shipbuilding
Construction
