| Specifications | ASTM B446 / ASME SB446 |
| Dimension Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Bar Diameter | 3 ~ 800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm. Width: 10 to 500mm. |
| Square bar size | 4 to 100mm |
| Rectangular Bars | Size: 33 x 30mm to 295 x 1066mm. Thickness: 3.0 to 12.0mm. |
| Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2 to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients requirements |
| Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Inconel 625 | 2.4856 | N06625 | NCF 625 | NA 21 | ХН75МБТЮ | NC22DNB4M | NiCr22Mo9Nb |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015max | - | 5.0 max | 58.0 min | 20.0 - 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
If you are looking for best prices for Inconel 625 Bars, Inconel 625 Rod, Inconel 625 Flat Bar email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Inconel 625 Round Bar Price | US $999-2500 / Ton |
| Inconel 625 Bar Price | US $1990-3900 / Ton |
| Inconel 625 Square Bar Price | US $800-2100 / Ton |
| Alloy 625 Round Bar Price in India | S $1000.0-3000.0 / Ton |
| Inconel Alloy 625 Hex Bar Price | US $300-2700 / Ton |
| Inconel Alloy 625 Rod Rate | US $1000-2500 / Ton |
| Alloy 625 Triangle Bar Price | US $1500-2625 / Ton |
| 625 Inconel Alloy Rectangular Bar Prices | US $2200-4000 / Ton |
| Inconel 625 Bright Bar Price List | US $1.2-4.7 / Kilogram |
| Inconel 625 Rod Price Per KG in India | US $1,600.00-2,200.00 / Ton |
| Type | Sizes in milimeter | Sizes in inches | Tolerance |
| Peeled and Polished | 40.00 - 150.00 | 1.50 - 6.00 | h11, h11-DIN 1013 |
| Cold Drawn and Polish | 3.00 to 75.00 | 1/8 to3.00 | h8 to h11 |
| Cold Drawn and Ground | 10.00 to 75.00 | 5/6 to 2.50 | h8 to h11 |
| Peeled nd Ground | 20.00 - 50.00 | 3/4 - 2.00 | h9 to h11 |
Inconel 625 Round Bars Standard lengths of 2000 mm up to 6000 mm.
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
| Diameter | Weight Chart | Dia | Weight Chart |
| (mm) | per metre (kg) | (in) | per metre (kg) |
| 3mm | 0.06 | 1/8" | 0.06 |
| 4mm | 0.10 | 3/16" | 0.14 |
| 5mm | 0.16 | 1/4" | 0.25 |
| 6mm | 0.22 | 5/16" | 0.39 |
| 7mm | 0.30 | 3/8" | 0.56 |
| 8mm | 0.40 | 7/16" | 0.77 |
| 10mm | 0.62 | 1/2" | 1.00 |
| 12mm | 0.89 | 9/16" | 1.22 |
| 14mm | 1.22 | 5/8" | 1.56 |
| 15mm | 1.40 | 11/16" | 1.89 |
| 16mm | 1.59 | 3/4" | 2.25 |
| 18mm | 2.01 | 7/8" | 3.07 |
| 20mm | 2.48 | 1" | 4.03 |
| 22mm | 3.00 | ||
| 24mm | 3.57 | ||
| 25mm | 3.88 |
| Diameter or Width (mm) |
Weight per meter | Sectional Area | Perimeter | |||
| Square (kg) |
Round (kg) |
Square (cm²) |
Round (cm²) |
Square (cm) |
Round (cm) |
|
| 5.0 | 0.20 | 0.15 | 0.25 | 0.20 | 2.0 | 1.57 |
| 5.5 | 0.24 | 0.19 | 0.30 | 0.24 | 2.2 | 1.78 |
| 6.0 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 7.0 | 0.38 | 0.30 | 0.49 | 0.38 | 2.8 | 2.20 |
| 8.0 | 0.50 | 0.39 | 0.64 | 0.50 | 3.2 | 2.51 |
| 9.0 | 0.64 | 0.50 | 0.81 | 0.64 | 3.6 | 2.83 |
| 10 | 0.73 | 0.63 | 1.00 | 0.79 | 4.0 | 3.14 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.40 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 18 | 2.54 | 2.00 | 3.24 | 2.54 | 7.2 | 5.65 |
| 20 | 3.14 | 2.47 | 4.00 | 3.14 | 8.0 | 6.28 |
| 22 | 3.80 | 2.98 | 4.84 | 3.80 | 8.8 | 6.91 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10.0 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.80 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16.00 | 12.57 | 16.0 | 12.57 |
| 45 | 15.90 | 12.49 | 20.25 | 15.90 | 18.0 | 14.14 |
| 50 | 19.62 | 15.41 | 25.00 | 19.64 | 20.0 | 15.71 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64.00 | 50.27 | 32.0 | 25.13 |
Ask Free Sample of Inconel 625 Bar, Rods, Round Bar Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM B446 Inconel 625 Bars Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Compression Test
Bending Test
Impact Test
Torsion Test
Tensile Test
Brinell/Rockwell Hardness Test
| CD | Cold drawn | P | Polished |
| CG | Centreless ground | HF | Hot finished |
| BD | Bright drawn | SRE | Slit rolled edge |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| ST | Smooth turned | PR | Peeled and reeled |
| EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Finland SFS |
Austria ONORM |
Russia GOST |
| EN 10095 (2.4856) | 625 | 2.4856 | NCF 625 | NC22DNB4M | NA 21 | - | - | - | - | - | - | - | ХН75МБТЮ |
| Products We Supplied | Description | Country |
| 625 Inconel Square Bar Weight | 8mm Inconel 625 Square Sar | Estonia, Vietnam, Denmark, Hungary |
| ASTM B446 Nickel Alloy 625 Rods | Inconel 625 3mm to 50mm Rods | Oman, Azerbaijan, Gambia, Belarus, South Africa |
| 625 Inconel Polished Bars | Polished UNS N06625 Bars | Bulgaria, Kuwait, Nepal, Bhutan |
| Inconel Alloy 625 Hex Bar Sizes in MM | JIS NCF 625 Hexagonal Bar | Yemen, Slovakia, Puerto Rico, Mongolia, Romania |
| ASME SB446 Inconel 625 Bars | 2.4856 Cold Rolled Bars | Taiwan, Belgium, New Zealand, Portugal | Inconel 625 Rectangular Bar | 625 Inconel Cold Drawn Rectangular Bar | Australia, Hong Kong, Singapore, Switzerland |
| Inconel Alloy 625 Rectangular Bars | 3.0 to 12.0mm Thickness Inconel 625 Rectangular Bar | Chile, Czech Republic, Jordan, Nigeria, Ecuador |
| Inconel 625 Round Bars | UNS N06625 Hot Rolled Rods Supply | Serbia, Venezuela, Malaysia, Germany |
Power Generation
Construction
Shipbuilding
Aerospace
Heavy Equipment
Automotive
Chemical
Oil & Gas
