| Standard | ASTM F467 / ASME SF467 |
| Bolt / Screw Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Nuts Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Washers Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Machine Screws Size | M1.6 – M12 |
| Self Tapping Screw Size | No.2 – No. 14 |
| Length | 3 mm to 200 mm |
| Threads | UNF, BSW, BSF, METRIC, UNC, or as required |
| Fasteners |
|
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production Process | M24-M100: hot forging , M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| Monel K500 | 2.4375 | N05500 | – | – | – | – | – |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel K500 | 0.25 max | 1.5 max | 0.5 max | 0.010 max | 27.00 – 33.00 | 0.5 – 2 | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel K500 | 8.44 g/cm3 | 1350 °C (2460 °F) | Psi – 160000 , MPa – 1100 | Psi – 115000 , MPa – 790 | 20 % |
If you are looking for best prices for Monel K500 Fasteners, Alloy K500 Stud Bolt, Alloy K500 Fasteners email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Monel K500 Nut Bolt Price Per Kg | US $1.99-200 / Kg |
| ASTM F467 Monel K500 Hexagon Head Screw | US $1290-4900 / Ton |
| Cost Per Kg of Alloy K500 Heavy Hex Nuts | US $99-1100 / Kg |
| Monel K500 Washer Price | S $1.00-900.0 / Kg |
| Monel K500 Self Locking Nuts Price Per Kg | US $190-1990 / Ton |
| Alloy K500 Heavy Hex Bolt price | US $1000-4500 / Ton |
| Monel K500 Anchor Fasteners Price List | US $1500-2K500 / Ton |
| Monel K500 Bolt Price List | US $2200-K5000 / Ton |
| Monel K500 Socket Head Screw Price | US $1.2-3.7 / Kilogram |
| Monel K500 Allen Cap Screw Price | US $1,100.00-2,100.00 / Ton |
| Size | Nominal (Major) Diameter [in] |
Coarse Thread (UNC) | Fine Thread (UNF) | ||||
| Threads Per Inch |
Tensile Stress Area [in2] |
Minor Area [in2] |
Threads Per Inch |
Tensile Stress Area [in2] |
Minor Area [in2] |
||
| #0 | 0.0600 | --- | --- | --- | 80 | 0.00180 | 0.00151 |
| #2 | 0.0860 | 56 | 0.00370 | 0.00310 | 64 | 0.00394 | 0.00339 |
| #4 | 0.1120 | 40 | 0.00604 | 0.00496 | 48 | 0.00661 | 0.00566 |
| #5 | 0.1250 | 40 | 0.00796 | 0.00672 | 44 | 0.00830 | 0.00716 |
| #6 | 0.1380 | 32 | 0.00909 | 0.00745 | 40 | 0.01015 | 0.00874 |
| #8 | 0.1640 | 32 | 0.0140 | 0.01196 | 36 | 0.01474 | 0.01285 |
| #10 | 0.1900 | 24 | 0.0175 | 0.01450 | 32 | 0.0200 | 0.0175 |
| 1/4" | 0.2500 | 20 | 0.0318 | 0.0269 | 28 | 0.0364 | 0.0326 |
| 5/16" | 0.3125 | 18 | 0.0524 | 0.0454 | 24 | 0.0580 | 0.0524 |
| 3/8" | 0.3750 | 16 | 0.0775 | 0.0678 | 24 | 0.0878 | 0.0809 |
| 7/16" | 0.4375 | 14 | 0.1063 | 0.0933 | 20 | 0.1187 | 0.1090 |
| 1/2" | 0.5000 | 13 | 0.1419 | 0.1257 | 20 | 0.1599 | 0.1486 |
| 9/16" | 0.5625 | 12 | 0.182 | 0.162 | 18 | 0.203 | 0.189 |
| 5/8" | 0.6250 | 11 | 0.226 | 0.202 | 18 | 0.256 | 0.240 |
| 3/4" | 0.7500 | 10 | 0.334 | 0.302 | 16 | 0.373 | 0.351 |
| 7/8" | 0.8750 | 9 | 0.462 | 0.419 | 14 | 0.509 | 0.480 |
| 1" | 1.0000 | 8 | 0.606 | 0.551 | 12 | 0.663 | 0.625 |
| 1-1/8" | 1.1250 | 7 | 0.763 | 0.693 | 12 | 0.856 | 0.812 |
| 1-1/4" | 1.2500 | 7 | 0.969 | 0.890 | 12 | 1.073 | 1.024 |
| 1-3/8" | 1.3750 | 6 | 1.155 | 1.054 | 12 | 1.315 | 1.260 |
| 1-1/2" | 1.5000 | 6 | 1.405 | 1.294 | 12 | 1.581 | 1.521 |
| 1-3/4" | 1.7500 | 5 | 1.90 | 1.74 | --- | --- | --- |
| 2" | 2.0000 | 4.5 | 2.50 | 2.30 | --- | --- | --- |
The following table of clearance holes was adapted from ASME B18.2.8. The minimum hole diameters are given.
| Bolt Size | Bolt Dia. [in] | Normal Fit [in] | Close Fit [in] | Loose Fit [in] |
| #0 | 0.0600 | 0.076 | 0.067 | 0.094 |
| #2 | 0.0860 | 0.102 | 0.094 | 0.116 |
| #4 | 0.1120 | 0.128 | 0.120 | 0.144 |
| #5 | 0.1250 | 0.156 | 0.141 | 0.172 |
| #6 | 0.1380 | 0.170 | 0.154 | 0.185 |
| #8 | 0.1640 | 0.196 | 0.180 | 0.213 |
| #10 | 0.1900 | 0.221 | 0.206 | 0.238 |
| 1/4" | 0.2500 | 0.281 | 0.266 | 0.297 |
| 5/16" | 0.3125 | 0.344 | 0.328 | 0.359 |
| 3/8" | 0.3750 | 0.406 | 0.391 | 0.422 |
| 7/16" | 0.4375 | 0.469 | 0.453 | 0.484 |
| 1/2" | 0.5000 | 0.562 | 0.531 | 0.609 |
| 5/8" | 0.6250 | 0.688 | 0.656 | 0.734 |
| 3/4" | 0.7500 | 0.812 | 0.781 | 0.906 |
| 7/8" | 0.8750 | 0.938 | 0.906 | 1.031 |
| 1" | 1.0000 | 1.094 | 1.031 | 1.156 |
| 1-1/8" | 1.1250 | 1.219 | 1.156 | 1.312 |
| 1-1/4" | 1.2500 | 1.344 | 1.281 | 1.438 |
| 1-3/8" | 1.3750 | 1.500 | 1.438 | 1.609 |
| 1-1/2" | 1.5000 | 1.625 | 1.562 | 1.734 |
The following table of hex nut dimensions was adapted from ASME B18.2.2, Table 1-1, "Dimensions of Square and Hex Machine Screw Nuts." This table is used for smaller size hardware.
| Size | Nominal (Major) Diameter [in] |
Width Across Flats | Thickness | ||
| Nominal [in] | Minimum [in] | Minimum [in] | Maximum [in] | ||
| #0 | 0.060 | 5/32"(0.156) | 0.150 | 0.043 | 0.050 |
| #2 | 0.086 | 3/16"(0.188) | 0.180 | 0.057 | 0.066 |
| #4 | 0.112 | 1/4"(0.250) | 0.241 | 0.087 | 0.098 |
| #6 | 0.138 | 5/16"(0.312) | 0.302 | 0.102 | 0.114 |
| #8 | 0.164 | 11/32"(0.344) | 0.332 | 0.117 | 0.130 |
| #10 | 0.190 | 3/8"(0.375) | 0.362 | 0.117 | 0.130 |
| 1/4" | 0.250 | 7/16"(0.438) | 0.423 | 0.178 | 0.193 |
| 5/16" | 0.312 | 9/16"(0.562) | 0.545 | 0.208 | 0.225 |
| 3/8" | 0.375 | 5/8"(0.625) | 0.607 | 0.239 | 0.257 |
The following table of hex nut dimensions was adapted from ASME B18.2.2, Table 4, "Dimensions of Hex Nuts and Hex Jam Nuts."
| Size | Nominal (Major) Diameter [in] |
Width Across Flats | Thickness | ||
| Minimum [in] | Maximum [in] | Minimum [in] | Maximum [in] | ||
| 1/4" | 0.2500 | 0.428 | 0.438 | 0.212 | 0.226 |
| 5/16" | 0.3125 | 0.489 | 0.500 | 0.258 | 0.273 |
| 3/8" | 0.3750 | 0.551 | 0.563 | 0.320 | 0.337 |
| 7/16" | 0.4375 | 0.675 | 0.688 | 0.365 | 0.385 |
| 1/2" | 0.5000 | 0.736 | 0.750 | 0.427 | 0.448 |
| 9/16" | 0.5625 | 0.861 | 0.875 | 0.473 | 0.496 |
| 5/8" | 0.6250 | 0.922 | 0.938 | 0.535 | 0.559 |
| 3/4" | 0.7500 | 1.088 | 1.125 | 0.617 | 0.665 |
| 7/8" | 0.8750 | 1.269 | 1.312 | 0.724 | 0.776 |
| 1" | 1.0000 | 1.450 | 1.500 | 0.831 | 0.887 |
| 1-1/8" | 1.1250 | 1.631 | 1.688 | 0.939 | 0.999 |
| 1-1/4" | 1.2500 | 1.812 | 1.875 | 1.030 | 1.094 |
| 1-3/8" | 1.3750 | 1.994 | 2.062 | 1.138 | 1.206 |
| 1-1/2" | 1.5000 | 2.175 | 2.250 | 1.245 | 1.317 |
| 1-5/8" | 1.6250 | 2.350 | 2.430 | 1.364 | 1.416 |
| 1-3/4" | 1.7500 | 2.538 | 2.625 | 1.460 | 1.540 |
| 1-7/8" | 1.8750 | 2.722 | 2.813 | 1.567 | 1.651 |
| 2" | 2.0000 | 2.900 | 3.000 | 1.675 | 1.763 |
The following table of flat washer dimensions was adapted from ASME B18.21.1, Table 11 for Type A Plain Washers. Type A washers come in 2 series: Narrow and Wide.
| Size | Basic Dia. [in] | Series | Inner Dia, Basic [in] |
Outer Dia, Basic [in] |
Thickness, Basic [in] |
| #0 | 0.0600 | --- | 0.078 | 0.188 | 0.020 |
| #2 | 0.0860 | --- | 0.094 | 0.250 | 0.020 |
| #4 | 0.1120 | --- | 0.125 | 0.312 | 0.032 |
| #6 | 0.1380 | --- | 0.156 | 0.375 | 0.049 |
| #8 | 0.1640 | --- | 0.188 | 0.438 | 0.049 |
| #10 | 0.1900 | --- | 0.219 | 0.500 | 0.049 |
| 1/4" | 0.2500 | Narrow | 0.281 | 0.625 | 0.065 |
| 1/4" | 0.2500 | Wide | 0.312 | 0.734 | 0.065 |
| 5/16" | 0.3125 | Narrow | 0.344 | 0.688 | 0.065 |
| 5/16" | 0.3125 | Wide | 0.375 | 0.875 | 0.083 |
| 3/8" | 0.3750 | Narrow | 0.406 | 0.812 | 0.065 |
| 3/8" | 0.3750 | Wide | 0.438 | 1.000 | 0.083 |
| 7/16" | 0.4375 | Narrow | 0.469 | 0.922 | 0.065 |
| 7/16" | 0.4375 | Wide | 0.500 | 1.250 | 0.083 |
| 1/2" | 0.5000 | Narrow | 0.531 | 1.062 | 0.095 |
| 1/2" | 0.5000 | Wide | 0.562 | 1.375 | 0.109 |
| 9/16" | 0.5625 | Narrow | 0.594 | 1.156 | 0.095 |
| 9/16" | 0.5625 | Wide | 0.625 | 1.469 | 0.109 |
| 5/8" | 0.6250 | Narrow | 0.656 | 1.312 | 0.095 |
| 5/8" | 0.6250 | Wide | 0.688 | 1.750 | 0.134 |
| 3/4" | 0.7500 | Narrow | 0.812 | 1.469 | 0.134 |
| 3/4" | 0.7500 | Wide | 0.812 | 2.000 | 0.148 |
| 7/8" | 0.8750 | Narrow | 0.938 | 1.750 | 0.134 |
| 7/8" | 0.8750 | Wide | 0.938 | 2.250 | 0.165 |
| 1" | 1.0000 | Narrow | 1.062 | 2.000 | 0.134 |
| 1" | 1.0000 | Wide | 1.062 | 2.500 | 0.165 |
| 1-1/8" | 1.1250 | Narrow | 1.250 | 2.250 | 0.134 |
| 1-1/8" | 1.1250 | Wide | 1.250 | 2.750 | 0.165 |
| 1-1/4" | 1.2500 | Narrow | 1.375 | 2.500 | 0.165 |
| 1-1/4" | 1.2500 | Wide | 1.375 | 3.000 | 0.165 |
| 1-3/8" | 1.3750 | Narrow | 1.500 | 2.750 | 0.165 |
| 1-3/8" | 1.3750 | Wide | 1.500 | 3.250 | 0.180 |
| 1-1/2" | 1.5000 | Narrow | 1.625 | 3.000 | 0.165 |
| 1-1/2" | 1.5000 | Wide | 1.625 | 3.500 | 0.180 |
| 1-5/8" | 1.6250 | --- | 1.750 | 3.750 | 0.180 |
| 1-3/4" | 1.7500 | --- | 1.875 | 4.000 | 0.180 |
| 1-7/8" | 1.8750 | --- | 2.000 | 4.250 | 0.180 |
| 2" | 2.0000 | --- | 2.125 | 4.500 | 0.180 |
Ask Free Sample of Monel K500 Fastener, Bolts, Nuts, Washer. Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM F467 Monel K500 Fasteners Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Shear Test
Fatigue Test
Biaxial Test
Creep Test
Drop Weight Test
Flexure Test
| Powder coating | Zinc and yellow plated |
| Zinc and de-embrittled | Stayblack finish |
| Sherardised | Nickel |
| Green chromate | Geomet |
| Galvanised | Electro brass plated |
| Chrome | Chemical black |
| EU EN |
USA - |
Germany DIN,WNr |
Japan JIS |
France AFNOR |
England BS |
Italy UNI |
China GB |
Sweden SS |
Poland PN |
Czechia CSN |
Finland SFS |
Austria ONORM |
Russia GOST |
| 2.4375 | K500 UNS N05500 |
2.4375 | NW 5500 | - | NA 18 | - | - | - | - | - | - | - | - |
| Products We Supplied | Description | Country |
| Monel K500 Fasteners | UNS N05500 U Bolts Supply | Venezuela, Serbia, Malaysia, Germany |
| ASTM F467 Monel K500 Fasteners | 2.4375 Nut Bolt Weight Chart In Kg | Azerbaijan, South Africa, Belarus, Gambia, Oman |
| Monel K500 Bolts and Nuts Price List | N05500 Alloy Eye Bolts | Puerto Rico, Mongolia, Slovakia, Romania, Yemen |
| Monel Alloy K500 Fasteners Manufacturers | 2.4375 Monel Double Ended Studs In India | Singapore, Switzerland, Australia, Hong Kong |
| ASME SF467 Monel K500 Fasteners In India | N05500 Acorn Nuts Manufacturers In India | Belgium, Portugal, New Zealand, Taiwan |
| Monel GOST - Fastener | Monel K500 Nyloc Nuts Manufacturers In India | Nigeria, Czech Republic, Jordan, Ecuador, Chile |
| Monel K500 Bolt Torque Chart | UNS N05500 Carriage Bolts Near Me | Kuwait, Nepal, Bhutan, Bulgaria |
| Monel® Alloy K500 Spring Washer | Monel K500 Flat Washers | Hungary, Vietnam, Estonia, Denmark |
