| Specifications | ASTM A276, ASTM A479, AMS 5513, AMS 5511, AMS 5647 |
| Dimension Standard | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Bar Diameter | 3 ~ 800mm |
| Hex Bar size | 2-100mm A/F |
| Flat bar size | Thickness: 2 -100mm. Width: 10 to 500mm. |
| Square bar size | 4 to 100mm |
| Rectangular Bars | Size: 33 x 30mm to 295 x 1066mm. Thickness: 3.0 to 12.0mm. |
| Hollow Bars | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2 to 495mm Diameter |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients requirements |
| Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Bars Condition | Hardened & tempered, annealed |
| Cold Rolled Bar Technique | Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Form | Round, Rod, T-Bar, Channel Bar, Precision Ground Bar, Flat Bar, Square, Blocks, Round Rod, Rings, Hollow, Triangle, Rectangle, Hex (A/F), Threaded, Half Round Bar, Profiles, Billet, Ingot, I/H Bar, Forging etc. |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 310 | 1.4841 | S31000 | SUS 310 | 310S24 | 20Ch25N20S2 | – | X15CrNi25-20 |
| SS 310S | 1.4845 | S31008 | SUS 310S | 310S16 | 20Ch23N18 | – | X8CrNi25-21 |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | Fe |
| SS 310 | 0.015 max | 2.0 max | 0.15 max | 0.020 max | 0.015 max | 24.00 – 26.00 | 0.10 max | 19.00 – 21.00 | 54.7 min |
| SS 310S | 0.08 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 24.00 – 26.00 | 0.75 max | 19.00 – 21.00 | 53.095 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.9 g/cm3 | 1402 °C (2555 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 40 % |
If you are looking for best prices for 310 Stainless Steel Bars, 310 Stainless Steel Rod, 310 SS Flat Bar email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| 310 Stainless Steel Round Bar Price | US $999-2500 / Ton |
| 310 Stainless Steel Bar Price | US $1990-3900 / Ton |
| 310 Stainless Steel Square Bar Price | US $800-2100 / Ton |
| SS 310 Round Bar Price in India | S $1000.0-3000.0 / Ton |
| SS 310 Hex Bar Price | US $300-2700 / Ton |
| SS 310 Rod Rate | US $1000-2500 / Ton |
| SS 310S Triangle Bar Price | US $1500-2600 / Ton |
| 310S SS Rectangular Bar Prices | US $2200-4000 / Ton |
| 310S Stainless Steel Bright Bar Price List | US $1.2-4.7 / Kilogram |
| Stainless Steel Rod 310 Price Per KG in India | US $1,600.00-2,200.00 / Ton |
| Type | Sizes in milimeter | Sizes in inches | Tolerance |
| Peeled and Polished | 40.00 - 150.00 | 1.50 - 6.00 | h11, h11-DIN 1013 |
| Cold Drawn and Polish | 3.00 to 75.00 | 1/8 to3.00 | h8 to h11 |
| Cold Drawn and Ground | 10.00 to 75.00 | 5/6 to 2.50 | h8 to h11 |
| Peeled nd Ground | 20.00 - 50.00 | 3/4 - 2.00 | h9 to h11 |
310S SS Round Bars Standard lengths of 2000 mm up to 6000 mm.
| 5.0 | 45.0 |
| 6.0 | 50.0 |
| 7.0 | 55.0 |
| 8.0 | 60.0 |
| 9.0 | 65.0 |
| 10.0 | 70.0 |
| 12.0 | 75.0 |
| 16.0 | 80.0 |
| 20.0 | 90.0 |
| 25.0 | 100.0 |
| 30.0 | 130.0 |
| 35.0 | 160.0 |
| 40.0 | 200.0 |
| Diameter | Weight Chart | Dia | Weight Chart |
| (mm) | per metre (kg) | (in) | per metre (kg) |
| 3mm | 0.06 | 1/8" | 0.06 |
| 4mm | 0.10 | 3/16" | 0.14 |
| 5mm | 0.16 | 1/4" | 0.25 |
| 6mm | 0.22 | 5/16" | 0.39 |
| 7mm | 0.30 | 3/8" | 0.56 |
| 8mm | 0.40 | 7/16" | 0.77 |
| 10mm | 0.62 | 1/2" | 1.00 |
| 12mm | 0.89 | 9/16" | 1.22 |
| 14mm | 1.22 | 5/8" | 1.56 |
| 15mm | 1.40 | 11/16" | 1.89 |
| 16mm | 1.59 | 3/4" | 2.25 |
| 18mm | 2.01 | 7/8" | 3.07 |
| 20mm | 2.48 | 1" | 4.03 |
| 22mm | 3.00 | ||
| 24mm | 3.57 | ||
| 25mm | 3.88 |
| Diameter or Width (mm) |
Weight per meter | Sectional Area | Perimeter | |||
| Square (kg) |
Round (kg) |
Square (cm²) |
Round (cm²) |
Square (cm) |
Round (cm) |
|
| 5.0 | 0.20 | 0.15 | 0.25 | 0.20 | 2.0 | 1.57 |
| 5.5 | 0.24 | 0.19 | 0.30 | 0.24 | 2.2 | 1.78 |
| 6.0 | 0.28 | 0.22 | 0.36 | 0.28 | 2.4 | 1.88 |
| 7.0 | 0.38 | 0.30 | 0.49 | 0.38 | 2.8 | 2.20 |
| 8.0 | 0.50 | 0.39 | 0.64 | 0.50 | 3.2 | 2.51 |
| 9.0 | 0.64 | 0.50 | 0.81 | 0.64 | 3.6 | 2.83 |
| 10 | 0.73 | 0.63 | 1.00 | 0.79 | 4.0 | 3.14 |
| 11 | 0.95 | 0.75 | 1.21 | 0.95 | 4.4 | 3.46 |
| 12 | 1.13 | 0.89 | 1.44 | 1.13 | 4.8 | 3.77 |
| 14 | 1.54 | 1.21 | 1.96 | 1.54 | 5.6 | 4.40 |
| 16 | 2.01 | 1.58 | 2.56 | 2.01 | 6.4 | 5.03 |
| 18 | 2.54 | 2.00 | 3.24 | 2.54 | 7.2 | 5.65 |
| 20 | 3.14 | 2.47 | 4.00 | 3.14 | 8.0 | 6.28 |
| 22 | 3.80 | 2.98 | 4.84 | 3.80 | 8.8 | 6.91 |
| 25 | 4.91 | 3.85 | 6.25 | 4.91 | 10.0 | 7.85 |
| 28 | 6.15 | 4.83 | 7.84 | 6.16 | 11.2 | 8.80 |
| 32 | 8.04 | 6.31 | 10.24 | 8.04 | 12.8 | 10.05 |
| 36 | 10.17 | 7.99 | 12.96 | 10.18 | 14.4 | 11.31 |
| 40 | 12.56 | 9.86 | 16.00 | 12.57 | 16.0 | 12.57 |
| 45 | 15.90 | 12.49 | 20.25 | 15.90 | 18.0 | 14.14 |
| 50 | 19.62 | 15.41 | 25.00 | 19.64 | 20.0 | 15.71 |
| 56 | 24.62 | 19.34 | 31.36 | 24.63 | 22.4 | 17.59 |
| 63 | 31.16 | 24.47 | 36.69 | 31.17 | 25.2 | 19.79 |
| 71 | 39.57 | 31.08 | 50.41 | 39.59 | 28.4 | 22.31 |
| 80 | 50.24 | 39.46 | 64.00 | 50.27 | 32.0 | 25.13 |
Ask Free Sample of 310 SS Bar, Rods, Round Bar Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A276 310 Stainless Steel Bars Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Compression Test
Bending Test
Impact Test
Torsion Test
Tensile Test
Brinell/Rockwell Hardness Test
| CD | Cold drawn | P | Polished |
| CG | Centreless ground | HF | Hot finished |
| BD | Bright drawn | SRE | Slit rolled edge |
| P&T | Peeled and turned | RT | Rough turned/peeled |
| CF | Cold finished | HRAP | Hot rolled annealed and pickled |
| ST | Smooth turned | PR | Peeled and reeled |
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| 310 | X 12 CrNi 25 21 | 1.4845 | X 22 CrNi 2520 | SUH 310 | 10KH23N18 | 310S24 | ||||
| 310S | Z 12 CN 25-20 | X 12 CrNi 25 20 | 1.4842 | X 5 CrNi 2520 | SUS 310S | 20KH25N20S2 | 23 61 | X 6 CrNi 25 20 |
| Products We Supplied | Description | Country |
| Stainless Steel 310 Hex Bar Sizes in MM | JIS SUS 310 Hexagonal Bar | Yemen, Slovakia, Puerto Rico, Mongolia, Romania |
| ASTM A276 310 Rods | SS 310 3mm to 50mm Rods | Belarus, Azerbaijan, Gambia, South Africa, Oman |
| 310 Stainless Steel Rectangular Bar | 310 SS Cold Drawn Rectangular Bar | Australia, Switzerland, Hong Kong, Singapore |
| Stainless Steel 310S Rectangular Bars | 3.0 to 12.0mm Rhickness SS 310S Rectangular Bar | Ecuador, Czech Republic, Chile, Nigeria, Jordan | Stainless Steel 310S Round Bars | UNS S31000 Hot Rolled Rods Supply | Serbia, Venezuela, Germany, Malaysia |
| 310S Stainless Steel Polished Bars | Polished UNS S31008 Bars | Kuwait, Bulgaria, Nepal, Bhutan |
| 310S Stainless Steel Square Bar Weight | 8mm Stainless Steel 310S Square Sar | Estonia, Denmark, Vietnam, Hungary |
| ASME SA276 310 Stainless Steel Bars | 1.4841 Cold Rolled Bars | Belgium, Portugal, New Zealand, Taiwan |
Power Generation
Construction
Shipbuilding
Aerospace
Heavy Equipment
Automotive
Chemical
Oil & Gas
