| Specifications | ASTM A182 / ASME SA182 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Dimensions | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Types | Socketweld Fittings, Screwed-Threaded Fittings |
| Pressure Rating | Threaded End-2000lb/ 3000lb/ 6000lbs Socket-weld End-3000/ 6000/ 9000lbs |
| Thread | NPT, BSPT, BSPP |
| Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Origin & Mills | Japanese, Indian, USA, Korean, European, Ukraine, Russian |
| Specialized manufacturer of | 90º Elbows, 45º Elbows, Tees, Cross, Couplings, Inserts, Caps, Nipples, and Unions, Forged Pipe Fittings, Socket Weld & Threaded, Equal Tees & Reducing Tees, 90° & 45° Elbows, Plugs |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| 253 MA | 1.4835 | S30815 |
| Grade | – | C | Mn | Si | P | S | Cr | Ni | N | Ce |
| 253MA / S30815 | min. max. | 0.05 0.10 | – 0.80 | 1.40 2.00 | – 0.040 | – 0.030 | 20.0 22.0 | 10.0 12.0 | 0.14 0.20 | 0.03 0.08 |
| Grade | Tensile Strength (MPa) min |
Yield Strength 0.2% Proof (MPa) min |
Elongation (% in 50mm) min | Hardness | Hardness |
| – | – | – | – | Rockwell B (HR B) max |
Brinell (HB) max |
| 253MA | 600 | 310 | 40 | 95 | 217 |
If you are looking for best prices for 253MA Stainless Steel Forged Fittings, SS 253MA BSP Elbow, 253MA Stainless Steel Union email us on info@duplexsteelalloys.com or call us on +91 9664408767
| Product | Price |
| Custom Size 2000 LB, 1 1/2 Inch SS 253MA Socket Weld Elbow Price | US $ 0.5-1.0 / Piece |
| ASME B16.11 SS 253MA Forged Socket weld Fittings Price | US $ 1.00-4000.0 / Piece |
| 253MA Stainless Steel Threaded Hex Nipple Price List | US $ 3.0-50.0 / Piece |
| NPS 1/2 to 2 253MA Stainless Steel Union Male x Female Price | US $ 2.5-60.0 / Piece |
| ANSI B16.11 253MA Stainless Steel 6 inch Forged Cap Price | US $ 1-2000 / Piece |
| 253MA Stainless Steel BSP Fittings | US $ 1.2 / Piece |
| ASTM A182 Grade F04 Forged Pipe Fittings Price | US $ 00.1-40 / Piece |
| ASME SA 182 253MA Stainless Steel Screwed Pipe Fittings 150lb Price List | US $ 3.0-50.0 / Piece |
| 253MA Stainless Steel End Cap Price List | US $ 3.87 / Piece |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A |
Center to End 45 Deg Elbow C |
O.D. of Band H |
Min. Wall Thick. G |
Length of Thread. Minimum (1) |
|||||||||
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| DN | NPS | End to End Couplings W |
End to End Caps P |
O.D. D | End Wall Thick. G Minimum |
Length of Thread. Minimum (1) |
||||
| Class 3000&Class 6000 | Class 3000 | Class 6000 | Class 3000 | Class 6000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 32 | 19 | … | 16 | 22 | 4.8 | … | 6.4 | 6.7 |
| 8 | 1/4 | 35 | 25 | 27 | 19 | 25 | 4.8 | 6.4 | 8.1 | 10.2 |
| 10 | 3/8 | 38 | 25 | 27 | 22 | 32 | 4.8 | 6.4 | 9.1 | 10.4 |
| 15 | 1/2 | 48 | 32 | 33 | 28 | 38 | 6.4 | 7.9 | 10.9 | 13.6 |
| 20 | 3/4 | 51 | 37 | 38 | 35 | 44 | 6.4 | 7.9 | 12.7 | 13.9 |
| 25 | 1 | 60 | 41 | 43 | 44 | 57 | 9.7 | 11.2 | 14.7 | 17.3 |
| 32 | 1-1/4 | 67 | 44 | 46 | 57 | 64 | 9.7 | 11.2 | 17.0 | 18.0 |
| 40 | 1-1/2 | 79 | 44 | 48 | 64 | 76 | 11.2 | 12.7 | 17.8 | 18.4 |
| 50 | 2 | 86 | 48 | 51 | 76 | 92 | 12.7 | 15.7 | 19.0 | 19.2 |
| 65 | 2-1/2 | 92 | 60 | 64 | 92 | 108 | 15.7 | 19.0 | 23.6 | 28.9 |
| 80 | 3 | 108 | 65 | 68 | 108 | 127 | 19.0 | 22.4 | 25.9 | 30.5 |
| 100 | 4 | 121 | 68 | 75 | 140 | 159 | 22.4 | 28.4 | 27.7 | 33.0 |
| ASME B16.11 Pressure-Temperature | |||||
| Temperature | Class | ||||
| 150 | 300 | ||||
| 1/4 - 1 inch. | 1 1/4 - 2 inch. | 2 1/2 - 3 inch. | |||
| (oF) | (oC) | ||||
| -20 to 150 | -29 to 66 | 300 | 2000 | 1500 | 1000 |
| 200 | 93 | 265 | 1785 | 1350 | 910 |
| 250 | 121 | 225 | 1575 | 1200 | 825 |
| 300 | 149 | 185 | 1360 | 1050 | 735 |
| 350 | 177 | 150 | 1150 | 900 | 650 |
| 400 | 204 | - | 935 | 750 | 560 |
| 450 | 232 | - | 725 | 600 | 475 |
| 500 | 260 | - | 510 | 450 | 385 |
| 550 | 288 | - | 300 | 300 | 300 |
| ANSI B16.11 American Standard Dimensional Tolerances | ||
| "A" - Threaded Center To Bottom | For Size 1/8" And 1/4" |
± 0.03" |
| 3/8", 1/2" And 3/4" | ± 0.06" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.08" | |
| 2-1/2", 3", And 4" | ± 0.10" | |
| "B" - Threaded Bore Diameter | For Size 1-1/2" And Smaller |
+ 0.020" - 0.000" |
| 2", 2-1/2", 3" And 4" | + 0.025" - 0.000" |
|
| "C" - Threaded Wall Thick. | Min. = 1.09 T (But Not Less Than 5/32") T = Wall Thickness Of Nominal Pipe Sizes |
|
| "D" - Bore Diameter Of Pipe Fitting | For Size 2" And Smaller |
± 0.030" |
| 2-1/2", 3" And 4" | ± 0.060" | |
| "E" - Threadeds- Bottom To Bottom - Full Couplings | For Size 1/8" And 1/4" |
± 0.06" |
| 3/8", 1/2" And 3/4" | ± 0.12" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.16" | |
| 2-1/2", 3", And 4" | ± 0.20" | |
| "F" - Bottom Of Threaded To Opposite Face - ANSI B16.11 Half Couplings | For Size 1/8" And 1/4" |
± 0.03" |
| 3/8", 1/2" And 3/4" | ± 0.06" | |
| 1", 1-1/4", 1-1/2" And 2" | ± 0.08" | |
| 2-1/2", 3", And 4" | ± 0.10" | |
| "G" - Gap Of Welding | Approx. 0.06" Before Welding Recommended Gap |
|
| "H" - Min. Flat | Min. Flat = 0.75 X Min. Threaded Wall Thick. |
|
Ask Free Sample of SS 253MA Forged Elbow, Tee, Coupling, Union Please Call +91 9664408767
Before being prepared for shipment to the customer, ASTM A182 253MA Stainless Steel Threaded Forged Fittings Testing should be constructed in accordance with applicable standards and thoroughly tested for potential flaws.
Hardness Test
PMI Testing
Ultrasonic Testing
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| 253MA | - | 1.4835 | - | - | X7CrNiSiNCe21-11 | - | - | - | - |
| Products We Supplied | Description | Country |
| Stainless Steel 253MA Forged 90° Elbow | UNS S30815 2000 LB, 1 1/2 Inch 90 Deg Elbow Supply | Saudi Arabia, Vietnam, Thailand, Indonesia |
| ASTM A182 253MA Stainless Steel Socket weld Reducing Tee | 3000#, 4 Inch, Threaded SS 253MA Pipe Coupling | Romania, UAE, Europe, Norway |
| Stainless Steel 253MA Threaded Equal Tee | 4 Inch UNS S30815 NPT Threaded Tee | Philippines, Taiwan, Kuwait, South Africa |
| Stainless Steel 253MA Forged Socket Weld Elbow | 3 Inch ASME B16.11 253MA SS SW Elbow | Canada, Australia, Nigeria, Ellington -United States |
| Stainless 253MA Forged Unequal Tee | 1/2 Inch, ASME B16.11 SS 253MA Socket Weld Tee | Colombia, Tunisia, Mongolia, Ukraine |
| SS 253MA Forged Pipe Coupling | 1.4835 CL3000, DN25, B16.11, Socket Reducing Tee | Netherlands, Venezuela, Belgium, Jordan, UK |
| SS 253MA Screwed Bushing | 1/2 inch ASME SS182 253MA Threaded Bushing | France, Mexico, Egypt, Malaysia |
| 253MA Stainless Steel Socket weld Half Coupling | 2-1/2 INCH 3000 LB 1/2 SW Half Coupling | Turkey, Morocco, Egypt, Canada, Germany |
| 253MA Stainless Steel NPT Threaded Pipe Fittings | 8 Inch UNS S30815 Forged Threaded Fittings | Finland, Maldives, Singapore, Uruguay, Costa Rica |
